MULTICOMP PRO MCNDI02S DIP Switch
The MCNDI-02S is a compact, low-profile DIP switch designed for space-efficient applications. It features gold-plated contacts for high reliability, splayed terminals for easy automatic insertion, and durable construction with insert molding and ultrasonic welding. Operating within -20°C to +85°C, this switch has a contact resistance of 50mΩ max, insulation resistance of 100MΩ at 500V, and dielectric strength of 500VAC for one minute. Suitable for vapor phase and IR-reflow soldering, it ensures dependable performance in various electronic circuits and control systems. A reliable choice for space-saving design needs.
MULTICOMP PRO MCNDI02S DIP Switch Specifications:
- Contact Arrangement: SPST
- Poles: 2
- Terminal Type: Splay
- Contact Rating: 25mA, 24VDC
- Contact Resistance: 50mΩ Max.
- Insulation Resistance: 100MΩ Min. at 500V DC
- Dielectric Strength: 500V AC/1 minute
- Operating Temperature: -20°C to +85°C
- Storage Temperature: -40°C to +85°C
- Travel: > 1mm
- Operating Life: 2,000 cycles
- Material: Gold-plated, durable plastic
- RoHS Compliant
- RoHS: Yes
- Dimensions: 6.02mm x 2.54mm (per pole), Splay terminal for automatic insertion
- Soldering: Suitable for vapor phase and IR-reflow processes
Buy the Multicomp Series DIP Switch: MCNDI-02S
Enhance your electronic assemblies with the reliable and space-efficient Multicomp Series MCNDI-02S DIP switch. Featuring gold-plated contacts, splayed terminals for easy automatic insertion, and a robust construction, this switch is suitable for vapor phase and IR-reflow soldering. It offers excellent dielectric strength, insulation resistance, and long cycle life, making it ideal for circuit control in compact devices. Purchase online today to benefit from quick delivery and quality assurance, ensuring consistent performance in your electronic solutions.
Order your Multicomp Series MCNDI-02S space-saving DIP switch today and ensure high-reliability switching in your electronic projects.
