MULTICOMP PRO MCSMT8540C3716 Magnetic Buzzer & Transducer
The Multicomp Pro Magnetic Buzzer and Transducer offers reliable sound emission with a minimum sound pressure level of 87dB at 10cm. Rated at 3.6V and operating between 2.5V to 4.5V, it features a coil resistance of 216Ω ±2.4Ω and a coil impedance of 7400Ω. The device has a resonant frequency of 2,670Hz, is housed in a durable black LCP case, and operates efficiently within -40°C to +80°C temperatures. Weighing 10.459 grams, it is suitable for various electronic signaling applications requiring RoHS compliance.
MULTICOMP PRO MCSMT8540C3716 Magnetic Buzzer & Transducer Specifications:
- Rated Voltage: 3.6V
- Operating Voltage: 2.5V to 4.5V
- Max. Rated Current: 80mA
- Coil Resistance: 216Ω ±2.4Ω
- Coil Impedance: 7400Ω
- Sound Pressure Level:-Minimum 87dB at 10cm
- Resonant Frequency: 2,670Hz
- Case Material: LCP 6130
- Color: Black
- Operating Temperature: -40°C to +80°C
- Store Temperature: -40°C to +85°C
- Weight: 10.459 grams
Buy the Buy Multicomp Magnetic Buzzer and Transducer Part Number MCSMT-8540C-3716 Online
Discover the reliable performance of the Multicomp Pro Magnetic Buzzer and Transducer, rated at 3.6V with a minimum sound pressure of 87dB. This RoHS-compliant device features a resonant frequency of 2,670Hz, coil resistance of 216Ω, and is housed in a durable black LCP case. Perfect for alert systems and electronic signaling, it operates efficiently from -40°C to +80°C, weighs 10.459 grams, and is suitable for various industrial and consumer applications. Purchase online now for quick integration into your devices.
Buy Multicomp Magnetic Buzzer and Transducer MCSMT-8540C-3716 now and experience high sound pressure and reliable performance for your electronic signaling needs.
