MULTICOMP PRO MCSVS1S04G PCB Socket
This 1.27mm pitch PCB socket with cap is designed for vertical, SMD mounting on single-row configurations, offering reliable electrical connections. Constructed from high-temperature plastic with gold-plated phosphor bronze contacts, it supports a current rating of 1A AC/DC and a voltage rating of 50V AC/DC. Suitable for various electronic assembly applications, it withstands voltage up to 500V AC for one minute, with an operating temperature range from -25°C to +105°C. Its precise dimensions facilitate easy surface-mount installation, ensuring secure and consistent connections in compact electronic devices.
MULTICOMP PRO MCSVS1S04G PCB Socket Specifications:
- Pitch: 1.27mm
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 500V AC for 1 minute
- Operating Temperature Range: -25°C to +105°C
- Insulator Material: High temp. plastic (UL94V-0)
- Contact Material: Phosphor Bronze
- Contact Finish: Gold plated
- Dimensions for 4POS option: Length 3.81mm, Width 5.46mm
- Type: Single row, vertical, SMD, with cap
- Compliance: RoHS
- Connector Type: PCB socket
- Number of Positions: Varies (1 to 9 positions available)
- Compatible with SMD PCB assembly
- Design includes secure cap to protect connections and ensure stability.
Buy the Multicomp Series 1.27 PCB Socket with Cap: MC-SVS1-S04-G
Enhance your electronic designs with our reliable 1.27mm pitch PCB socket featuring a protective cap, ideal for vertical SMD mounting and compact assemblies. Crafted from high-temperature plastic with gold-plated phosphor bronze contacts, it guarantees excellent electrical conductivity and durability. Rated at 1A and 50V, it supports up to 500V withstand voltage for a minute, perfect for demanding electronic environments. Easy to install on surface-mount boards, it provides secure connections, ensuring stability and performance for your electronic projects. Purchase online today for fast delivery and trusted quality.
Order your Multicomp Series 1.27 PCB Socket with Cap today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCSVS1S04G?
You can click on the BUY or RFQ button to purchase MCSVS1S04G from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCSVS1S04G?
You can download the MCSVS1S04G datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCSVS1S04G?
MULTICOMP PRO
