MULTICOMP PRO MCTB92F02M PCB Terminal Block
The MCTB-92F02M is a 2-position Eurostyle PCB terminal block designed for reliable electrical connections in industrial settings. It features tin-plated brass contacts and a durable PA66 housing for long-lasting performance. Equipped with a nickel-plated brass cage clamp and M3 steel screw thread, it supports wire sizes from 10AWG to 24AWG and has a PCB hole diameter of 1.7mm. Rated for a maximum load current of 30A and voltage of 300V, it ensures secure, stable wiring within a temperature range of -40°C to +105°C, ideal for automation and manufacturing equipment.
MULTICOMP PRO MCTB92F02M PCB Terminal Block Specifications:
- Pitch: 7.62mm complies with standards
- Number of Poles: 2
- Housing Material: PA66
- Cage Clamp: Brass, Ni Plated
- Contact Material: Brass, Tin Plated
- Screw Thread: M3, Steel, Zinc Plated
- Wire Size: 10AWG to 24AWG
- PCB Hole Diameter: 1.7mm
- Tightening Torque, Max.: 5.5Lb-in
- Operating Temperature: -40°C to +105°C
- Rated Current: 30A
- Rated Voltage: 300V
- Maximum Load Current: 30A
- Dimensions: Length approximately 13.8mm (0.543 inches)
- Physical Material: Steel, Brass, PA
Buy the Multicomp Pro MCTB92F02M – Reliable PCB Terminal Block for Industrial Applications
Purchase the Multicomp Pro PCB Terminal Block MCTB92F02M today for reliable industrial wiring solutions. Featuring tin-plated brass contacts and a durable PA66 housing, this terminal block ensures secure connections across a wide temperature range. Its M3 steel screw supports wire sizes from 10AWG to 24AWG, making it suitable for automation, manufacturing, and control panels. Rated at 30A and 300V, it offers excellent performance, stability, and easy installation, making it an essential component for industrial electrical systems.
Get Multicomp Pro MCTB92F02M today—built for secure connections, durability, and easy wiring in industrial environments.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCTB92F02M?
You can click on the BUY or RFQ button to purchase MCTB92F02M from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTB92F02M?
You can download the MCTB92F02M datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCTB92F02M?
MULTICOMP PRO
