MULTICOMP-PRO MCTC0525B5110T5G High Power Chip Resistor
This high-power chip resistor offers excellent pulse withstand performance, with a maximum working voltage of 150V and resistance tolerance of ±0.1%. Operating from -55°C to +155°C, it features industry-standard temperature coefficient of ±25ppm/°C, sn terminations, and high stability for demanding electronic applications requiring reliable pulse load capacity. It uses a 0805 case size, constructed with high-quality materials like silver resistive elements and Ni barriers, making it suitable for power electronics, high-frequency circuits, and precision measurement devices. Its RoHS compliance ensures environmentally responsible manufacturing.
MULTICOMP-PRO MCTC0525B5110T5G High Power Chip Resistor Specifications:
- Case Size: 0805
- Power Rating at 70°C: 0.125W (1/8W)
- Max. Working Voltage: 150V
- Resistance Tolerance: ±0.1%
- Resistance Range: 109 to 1MΩ
- Temperature Range: -55°C to +155°C
- Ambient Temperature: 270°C
- Dielectric Withstanding Voltage: 500V
- Temperature Coefficient: ±25ppm/°C
- Resistance Standard: E-96 for 0.1% tolerance, E-24 for 2% tolerance
- Construction includes high purity alumina substrate, Sn outer termination, Ni barrier middle, and Ag resistive element
Buy the Multicomp Series MCTCOS Resistors: 0805 Pulse Power High-Precision Resistance
Order the high power chip resistor online today and enhance your electronic designs with reliable pulse withstand, precise resistance, and stable operation under demanding conditions. Suitable for power electronics, high-frequency applications, and precision measurement devices, this resistor guarantees high stability, RoHS compliance, and excellent industry standards. Easy to install in 0805 footprint, it provides consistent performance from -55°C to +155°C, making it an essential component for engineers seeking durability and precision in their circuits. Get yours now for optimal electronic reliability.
Buy Multicomp Series MCTCOS chip resistors now and experience unmatched reliability and high pulse load performance for your demanding electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCTC0525B5110T5G?
You can click on the BUY or RFQ button to purchase MCTC0525B5110T5G from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTC0525B5110T5G?
You can download the MCTC0525B5110T5G datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCTC0525B5110T5G?
MULTICOMP-PRO
