MULTICOMP-PRO MCTDS08 Tri-State DIL Switch
The Tri-State DIL Switch is a versatile 3-position switch designed for reliable switching in electronic circuits. Constructed with a PBT high thermoplastic base and cover, along with nylon actuators, it offers durability and resistance to temperature variations. The switch features gold-plated alloy copper contacts for excellent conductivity, with a mechanical life of 2,000 cycles. Operating within -20°C to +70°C, it supports electrical ratings of 100mA at 50V DC and 25mA at 24V DC, making it ideal for automation and control systems requiring precise, multi-position switching, and robust performance.
MULTICOMP-PRO MCTDS08 Tri-State DIL Switch Specifications:
- Mechanical Life: 2,000 Operations Cycles
- Operation Force: 1,000gf Max.
- Stroke: 1mm
- Operation Temp: -20°C to +70°C
- Storage Temp: -40°C to +85°C
- Material: Base & Cover PBT High Thermoplastic, Actuators Nylon Thermoplastic
- Contact Material: Alloy Copper with Gold Plated
- Terminal: Brass with Tin Plated
- Contact Plating: Gold over Nickel
- Electrical Life: 2,000 cycles
- Non-Switching Rating: 100mA, 50V DC
- Switching Rating: 25mA, 24V DC
- Contact Resistance: 50MQ Max. initial, 100MQ Max. after life test
- Insulation Resistance: 100MQ min. at 500V DC
- Dielectric Strength: 500V AC/1 min.
- Circuit: 3 switching positions
- Physical Dimensions: Max length 5.90mm, width 3.26mm, height 8.50mm, Pin spacing 2.54mm
Buy the Buy multicomp:ro Tri-State DIL Switch Part Number MCTDS08 Online
Purchase the Tri-State DIL Switch today for reliable multi-position switching in your electronic projects. Built with durable materials like PBT thermoplastic and gold-plated contacts, it ensures long-lasting performance. Operating efficiently from -20°C to +70°C, it supports electrical ratings suitable for automation and control systems. With a mechanical life of 2,000 cycles, this switch is ideal for demanding industrial and electronic applications. Shop online for quick delivery and competitive prices, ensuring your project stays on track with high-quality, reliable components.
Get multicomp:ro Tri-State DIL Switch MCTDS08 today—designed for precision switching and durable operation.
