MULTICOMP PRO MCTG102M1AB1017P Axial Aluminium Capacitor
The axial aluminium electrolytic capacitor offers high stability and reliability for electronic applications, with a capacitance of 1000μF rated at 10V. Suitable for various industrial and power supply circuits, it features a compact design with a diameter of 10mm and length of 17mm. Operating within a temperature range of -40°C to +105°C, it has low leakage current, excellent dissipation factor, and satisfies JIS C5141 standards. Its construction includes a tinned copper seal and aluminum case, making it RoHS compliant and durable for long-term use.
MULTICOMP PRO MCTG102M1AB1017P Axial Aluminium Capacitor Specifications:
- Capacitance: 1000μF
- Working Voltage: 10V DC
- Diameter: 10mm
- Length: 17mm
- Operating Temperature Range: -40°C to +105°C
- Leakage Current: ≤ 0.02CV or 3μA (after 2 minutes at rated voltage)
- Dissipation Factor (Tan 8): 0.2 at 20°C, 120Hz
- Surge Voltage: 13V
- Impedance Z(+20°C): 16 at 120Hz
- Impedance Z(-40°C): 10 at 120Hz
- RoHS compliant
- Construction: Aluminum case with PVC sleeve, rubber seal, tinned copper wire
- Dimensions: Diameter 10mm, Length 17mm
Buy the Multicomp Series Axial Aluminium Electrolytic Capacitors: MCTG102M1AB1017P
Purchase the Multicomp Series axial aluminium electrolytic capacitor featuring 1000μF capacitance and 10V voltage rating online today. Its compact size of 10mm diameter and 17mm length allows easy integration into various electronic devices and power supplies. With a temperature range from -40°C to +105°C, it offers high stability, low leakage current, and excellent performance in industrial and commercial applications. RoHS compliance guarantees environmentally friendly manufacturing. Secure your supply and enhance your circuit's reliability by ordering this high-quality capacitor now!
Order your Multicomp Series axial aluminium electrolytic capacitor in 10V 1000μF today and ensure durable, reliable power management for your projects.
