MULTICOMP PRO SBR3506 Three Phase Bridge Rectifier
The SBR3506 is a silicon passivated three-phase bridge rectifier rated for 35A and 600V, ideal for converting AC to DC in power supply applications. This high-reliability component features diffused junctions with low forward voltage drop, high surge current capability, and is suitable for printed circuit boards. Its epoxy case with heat sink mounting ensures excellent thermal management, making it suitable for use in resistive or inductive loads. The device offers robust electrical performance with a maximum average forward current of 35A and a peak surge current of 420A, operating efficiently up to 160°C.
MULTICOMP PRO SBR3506 Three Phase Bridge Rectifier Specifications:
- Maximum Average Forward Current: 35A
- Peak Repetitive Voltage: 600V
- Working Peak Reverse Voltage: 600V
- Peak Non-Repetitive Reverse Voltage: 900V
- RMS Reverse Voltage: 560V
- Maximum Surge Current: 420A
- Peak Forward Voltage Drop: 12V at 12.5A
- Maximum Operating Temperature: -55°C to +160°C
- Thermal Resistance Junction to Case: 1.16 kW
- Thermal Resistance Case to Heatsink Mounting: 0.2 K/W
- Thermal Impedance Steady State: 142 kΩ
- Isolation Voltage from Case to Lead: 2,500 V
- Dimensions: Diameter 49.1 mm (1.93 inches), Mounting hole 24.1 mm (0.949 inches)
Buy the Multicomp Series SBR3506 Bridge Rectifier: 35A 600V
Order the Multicomp SBR3506 three-phase bridge rectifier online now and enjoy reliable power conversion for industrial and electronic projects. This high-performance component offers 35A capacity at 600V, diffused junction technology for low forward voltage, and high surge current handling. Designed with robust thermal management features, it ensures efficient operation in resistive or inductive loads, making it ideal for power supplies, motor drives, and industrial automation. Purchase online today for fast delivery and trusted quality.
Get Multicomp SBR3506 today—built for precision and long-lasting durability in power conversion applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SBR3506?
You can click on the BUY or RFQ button to purchase SBR3506 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SBR3506?
You can download the SBR3506 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SBR3506?
MULTICOMP PRO
