MULTICOMP PRO ME04050004 pluggable terminal block
The ME040-50004 is a 4-pole, 16A pluggable terminal block header with a through-hole vertical configuration. It features tin-plated brass solder pins and a green polyamide 66 insulating body. The component has a UL94V-0 flammability rating, an insulation resistance greater than 2000 MΩ at 200VDC, and an operational temperature range from -40°C to 105°C. Suitable for industrial applications, it is part of the Multicomp Pro product line, which is rated 4.6 out of 5 stars and comes with a 12-month limited warranty.
MULTICOMP PRO ME04050004 pluggable terminal block Specifications:
- Current Rating: 16 Amp AC300V
- Insulation Withstands Volt: AC2000V min
- Insulation Resistance: >2000 MΩ at 200VDC
- Operation Temperature: -40°C to +105°C
- Material: Polyamide 66 (UL94V-0)
- Pin Material: Brass, Tin-plated
- Pitch: 3.81mm (0.15")
- Pole Count: 4
- Vertical through-hole configuration
- Dimensions: not specified explicitly, compatible with standard 3.81mm pitch
- Flammability: UL94V-0
- Rated for industrial applications
Buy the Multicomp Pro ME04050004 – Reliable Pluggable Terminal Block for Industrial Applications
Enhance your industrial projects with the Multicomp Pro ME04050004 pluggable terminal block. Designed for high current capacity and durability, it features UL94V-0 rated polyamide insulation and brass solder pins for reliable connections. With a 16A rating and operating temperature range from -40°C to 105°C, it suits various industrial environments. Simplify your wiring with the vertical through-hole design, ensuring secure and maintenance-friendly connections. Purchase online today for dependable, high-quality terminal blocks that meet demanding industrial standards.
Buy Multicomp Pro ME04050004 now and experience unmatched reliability and high-performance terminal connections for industrial projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO ME04050004?
You can click on the BUY or RFQ button to purchase ME04050004 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part ME04050004?
You can download the ME04050004 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of ME04050004?
MULTICOMP PRO
