MULTICOMP-PRO MP000440 LED Indicator
This 5mm round LED lamp features a narrow angle of 15° and emits ultra orange red light with a peak wavelength of 635nm. It’s suitable for indicator and display applications, offering a luminous intensity of up to 17000mcd at 20mA and a forward voltage between 1.7V to 2.6V. Constructed with AllnGaP die material, it withstands a temperature range of -40°C to +85°C and includes water clear lens coverage. Easy to solder with recommended conditions, it is RoHS compliant and designed for dependable performance in various electronic projects.
MULTICOMP-PRO MP000440 LED Indicator Specifications:
- Diameter: 5mm (T-1 3/4)
- Emission Colour: Ultra Orange Red
- Peak Wavelength: 635nm
- Viewing Angle: 15 Degrees
- Luminous Intensity: 17000mcd at 20mA
- Forward Voltage: 1.7V to 2.6V
- Power Dissipation: 85mW
- Peak Forward Current: 100mA
- Recommended Operating Current: 20mA
- Reverse Voltage: 5 Volt
- Reverse Current: 10μA (VR = 5V)
- Electrostatic Discharge (ESD): 200 Volt
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature: 260°C for 5 seconds
Buy the Buy multicomp Ultra Orange Red 5mm Round Type Narrow Angle LED Part Number MP000440 Online
Get your multicomp Series MP000440 ultra orange red LED online today and experience dependable, bright illumination for indicator and display applications. This 5mm round LED with a narrow 15° viewing angle offers maximum visibility and high luminous intensity of up to 17000mcd at 20mA, making it suitable for rugged environments and precise signaling. Its water clear lens, peak wavelength of 635nm, and easy soldering characteristics ensure perfect performance in various electronic devices. Shop now for fast, secure delivery and elevate your project’s quality.
Order your multicomp Series MP000440 ultra orange red LED today and enhance your electronic projects with reliable, bright indicator lighting.
