MULTICOMP PRO MP000459 High Power Chip Resistor Kit
High Power Chip Resistor Kits offer a wide range of resistance values with high power ratings, suitable for various electronic applications. These kits feature resistors with a tolerance of 1%, constructed on high-purity alumina substrates, and are RoHS compliant. They are designed to operate at ambient temperatures up to +70°C, with detailed specifications including physical dimensions, resistance ranges from 10 ohms to 1 megaohm, and withstand voltages up to 500V. The resistors are marked with G2 coating, have Sn, Ni Barrier, and Ag resistive elements, ensuring durability and reliability in high-power electronic circuits.
MULTICOMP PRO MP000459 High Power Chip Resistor Kit Specifications:
- Power Rating: 1/10W (0.1W) to 2W
- Resistance Range: 10Ω to 1MΩ
- Tolerance: 1%
- Operating Temperature: -55°C to +155°C, Ambient +70°C
- Voltage Ratings: Up to 500V
- Construction: High-purity alumina substrate, G2 and G1 coating, Sn outer termination, Ni barrier, Ag resistive element
- Dimensions: Varies by kit, typical sizes from 1mm to 6.35mm in length
- Insulation Resistance: ≥ 1000 MΩ at 500V DC
- Dielectric Withstanding Voltage: 500V AC for 1 min
- Temperature Coefficient: < 400 PPM/°C
- Solderability: ≥ 95% coverage at 245°C, 2-3 sec dip
- Soldering Profile: Peak temperature 260°C, heating time 20-40 sec
- Load Life in Humidity: Resistance variation within 1.5% over 1000 hours at 70°C and 90-95% RH
- Resistance Change after Cycles: ≤ 1% after 5 temperature cycles
Buy the Multicomp Series High Power Chip Resistor Kits: MP000459
Order the multicomp high power chip resistor kit MP000459 today and enjoy reliable performance in demanding electronic circuits. These resistor kits cover resistance values from 10 ohms to 1 megaohm with a 1% tolerance, suitable for applications requiring high power ratings up to 0.2W. Designed with high-quality materials, they feature RoHS compliance, robust construction, and excellent thermal stability. Whether for prototyping or manufacturing, these resistor kits ensure precise, durable, and efficient performance for your electronic projects.
Get multicomp MP000459 high power chip resistor kit today—built for precision and long-lasting durability.
