MULTICOMP PRO MP002312 Multicore Cable
These multicore cables conform to Defence Standard 61-12 Part 4, featuring PVC insulation and sheathing, tinned copper conductors, and a flexible design suitable for high-density wiring in aerospace, military, and industrial applications. Available in various core counts and colors, they support voltage ratings up to 440V RMS at 1.6 kHz. The cables are designed with a minimum bending radius, effective insulation, and conductors with specified resistance, ensuring reliable performance in demanding environments. Ideal for electronic equipment requiring robust, RoHS-compliant wiring solutions.
MULTICOMP PRO MP002312 Multicore Cable Specifications:
- Voltage Rating: 250V RMS (7/0.1 mm conductors), 440V RMS (7/0.2 mm conductors)
- Conductors: Stranded tinned copper, 0.055mm² (7/0.1 mm), 0.22mm² (7/0.2 mm)
- Insulation: PVC (Polyvinyl Chloride)
- Sheath: PVC (Polyvinyl Chloride)
- Screen: TCWB (Tinned Copper Wire Braid) (optional)
- Core Identification: Colored cores including Red, Blue, Green, Yellow, White, Black, etc.
- Temperature Rating: Fixed -30°C to +70°C; Flexed -15°C to +70°C
- Minimum Bending Radius: 7.5 x overall diameter
- Nominal Diameter: ranges from approximately 2.7 mm to 10.8 mm depending on core count and thickness
- Maximum Resistance: 3840/km (7/0.1 mm), 920/km (7/0.2 mm)
- Standards: Defence Standard 61-12 Part 4
- Application: High density wiring in aerospace, military vehicles, computers, process control systems
- RoHS Compliant
Buy the Buy Multicomp Cables Part Number MP002312 Online
Order the Multicomp Multicore Cable part number MP002312 online today to benefit from durable PVC insulation and sheathing, tinned copper conductors, and high voltage ratings up to 440V RMS. Designed for aerospace, military, and industrial electronics, these cables support various core configurations with color coding for easy identification. Their robust construction and compliance with Defence Standard 61-12 Part 4 make them ideal for high-density wiring in critical environments. Purchase online now for quick delivery and quality performance in demanding applications.
Buy Multicomp MP002312 now and experience reliable, high-performance wiring solutions for demanding electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP002312?
You can click on the BUY or RFQ button to purchase MP002312 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP002312?
You can download the MP002312 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP002312?
MULTICOMP PRO
