MULTICOMP PRO MP002730 IP67 Connectors
The MP-T21 IP67 series connectors provide durable, weatherproof connections with bayonet coupling for quick assembly. Available in panel, cable, and inline configurations, these connectors handle indoor and outdoor environments with an IP67 rating. They support solder and screw terminations, suited for various applications like automation, process control, security, and industrial automation. Designed to fit 21mm cut-outs, they feature multiple pole configurations, from 2 to 12 poles, with an accompanying IP67 dust cap for enhanced protection. Made from nylon66 shells and brass contacts with gold plating, ensuring robust performance and longevity.
MULTICOMP PRO MP002730 IP67 Connectors Specifications:
- Material: Nylon66 shell, brass contacts with gold plating
- Ingress Protection: IP67
- Coupling Type: Bayonet
- Connector Options: Panel mount, cable mount, inline cable mount
- Operating Temperature: -40°C to +80°C
- Termination: Solder and screw
- Number of Contacts: 2, 3, 4, 5, 7, 9, 12
- Rated Current: 15-30A depending on contact size
- Rated Voltage: Up to 500V AC
- Test Voltage: 1500V AC for 1 min
- Contact Resistance: 1-5 mΩ
- Insulation Resistance: 2000 MΩ
- Mating Cycle: 500
- Dimensions: Fit 21mm panel cut-out, outer diameter range up to 12mm
- Additional: Suitable for outdoor, industrial, automation, security, medical, test and measurement applications
Buy the Buy multicomp IP67 Connectors Part Number MP002730 Online
Secure your automation setups with multicomp IP67 connectors MP002730. Featuring bayonet coupling, robust nylon66 shells, and gold-plated brass contacts, they ensure reliable, weatherproof connections for indoor and outdoor use. Available in multiple configurations with solder or screw terminations, these connectors support up to 12 contacts. Easy to install with a 21mm cut-out, they are perfect for process control, security, medical, and industrial automation. Order online today for fast, trusted delivery and enhance your connectivity solutions.
Buy multicomp IP67 connectors MP002730 now and experience reliable, weatherproof connections ideal for industrial automation and outdoor applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP002730?
You can click on the BUY or RFQ button to purchase MP002730 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP002730?
You can download the MP002730 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP002730?
MULTICOMP PRO
