MULTICOMP PRO MP003280 Industrial Power Supply
This 50W AC-DC power supply features compact DIN rail mounting and universal input voltage range from 90V AC to 264V AC, making it ideal for industrial automation, process control, and transportation systems. It offers high efficiency up to 83%, with protections including short circuit, over voltage, over current, and over temperature. The power supply includes LED indicators for DC power and low voltage faults, ensuring reliable operation in industrial environments. Its design facilitates easy installation with free air convection cooling and robust safety and EMC standards compliance.
MULTICOMP PRO MP003280 Industrial Power Supply Specifications:
- Input Voltage: 90V AC to 264V AC
- Input Frequency: 47-63 Hz
- Efficiency: Up to 83%
- Output Voltage: 12V or 24V (adjustable within range)
- Output Current: 4.2A (12V), 2.2A (24V)
- Ripple: 25mV (12V), 40mV (24V)
- Protection: Short circuit, over voltage, over current, over temperature
- Cooling: Free air convection
- Dimensions: 30mm (W) x 130mm (H) x 125mm (D)
- Weight: 270g
- Isolation Voltage: I/P-O/P 3 kV AC
- Safety Standards: UL, CE, FCC, CB
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +85°C
- MTBF: 200,000 hours
Buy the Multicomp Pro MP003280 – Reliable 50W Power Supply for Industrial Applications
Upgrade your industrial automation systems with the reliable 50W DIN rail power supply. Featuring universal AC input, high efficiency, and comprehensive protections, this power supply ensures stable operation for process control, factory automation, and transportation systems. Easy to install, with LED indicators for status monitoring, it guarantees optimal performance across a wide temperature range. Trust in its proven safety standards and long MTBF for peace of mind. Purchase online now to enhance your equipment's reliability and efficiency.
Buy Multicomp Pro MP003280 now and experience unmatched reliability and performance in industrial automation and process control.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP003280?
You can click on the BUY or RFQ button to purchase MP003280 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP003280?
You can download the MP003280 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP003280?
MULTICOMP PRO
