MULTICOMP PRO MP003364 Chip Resistor Kit
This is a 0805 size chip resistor kit featuring RoHS compliance, suitable for automated assembly, with 80 values in the E24 series from 1Ω to 1MΩ. The kit includes 8,000 pieces, with resistors marked according to industry standards, including 4-digit markings for large sizes. Designed for reliable performance in electronic circuits, these resistors have a tolerance of ±1%, with specifications compliant to MIL-STD testing standards like load life, temperature cycling, and humidity resistance. Ideal for manufacturing, repair, and prototyping of electronic devices.
MULTICOMP PRO MP003364 Chip Resistor Kit Specifications:
- Size: 0805
- Resistance Range: 1Ω to 1MΩ
- Series: E24
- Number of Values: 80
- Total Quantity: 8,000 pcs
- Tolerance: ±1%
- Marking: 4-digit for larger sizes, significant figures for smaller
- RoHS Compliant
- Performance: Load life at 125°C, 35% P, 1000 hours within ±1%, with measurements taken 24 hours post-test
- Temperature Coefficient: ±200PPM/°C for resistance below 100Ω; ±100PPM/°C for higher resistance
- Solderability: Minimum 95% coverage, tested at 245°C for 2-3 seconds
- Soldering Heat Resistance: Max resistance change of ±0.050Ω at 260°C for 10 seconds
- Humidity Resistance: Max resistance change of ±1% at 85°C/85% RH over 1000 hours
- Temperature Cycling: 1% max change over -55°C to +125°C, 100 cycles, measured after 24 hours
Buy the Multicomp 0805 Kit – Reliable Resistor for Industrial Applications
Order the Multicomp 0805 resistor kit online now and ensure high-quality components for your electronic projects. Featuring 80 values from 1Ω to 1MΩ, these resistors with ±1% tolerance are ideal for assembly, repair, and prototyping. The kit includes 8,000 pieces, marked according to industry standards for easy identification, and complies with RoHS regulations. Built for reliability, they withstand harsh conditions like humidity, temperature cycling, and soldering heat, delivering consistent performance for industrial, commercial, and DIY electronics applications.
Get Multicomp 0805 resistor kit today—built for precision and long-lasting durability in electronic manufacturing.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP003364?
You can click on the BUY or RFQ button to purchase MP003364 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP003364?
You can download the MP003364 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP003364?
MULTICOMP PRO
