MULTICOMP PRO MP004319 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse is designed for accurate circuit protection in electronic devices. Its axial leaded design measures 6.3mm x 32mm, with ceramic body and nickel-plated brass caps. It offers a rated current from 800mA to 30A and voltage ratings up to 250V AC/DC. Suitable for applications requiring reliable overcurrent protection, it features different lead wire diameters based on current ratings, and an interrupting rating up to 10,000 amperes at 125V AC. Its operating temperature ranges from -55°C to 125°C, ensuring durability in various environments.
MULTICOMP PRO MP004319 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm for 12A and less, 1.0 mm for 13A-19A, 1.2 mm for above 20A
- Dimensions: Diameter 6.3 mm, Length 32 mm, Total Length 33 mm with caps
- Operating Temperature Range: -55°C to 125°C
- Rated Current: 800mA to 30A
- Rated Voltage: Up to 250V AC/DC
- Interrupting Rating: Up to 10,000A at 125V AC
- Certification: UL Listed, CSA Certified, PSE
- Switching Capacity: 35A at 250V AC (up to 200A at 250V depending on rating)
Buy the Multicomp Series Ceramic Cartridge Fuse: MP004319
Purchase the Multicomp Series ceramic cartridge fuse MP004319 online today for dependable overload protection in electronic circuits. This axial leaded fuse features a ceramic body with nickel-plated brass caps, ideal for protecting devices from overcurrent conditions. With ratings spanning from 800mA up to 30A and voltage capacities up to 250V AC/DC, it ensures safety and durability in various applications. Its compact size and high interrupting rating make it a versatile choice for both industrial and consumer electronics, available now for quick online ordering.
Order your Multicomp Series ceramic cartridge fuse MP004319 today and ensure reliable circuit protection with high-current capacity and RoHS compliance.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004319?
You can click on the BUY or RFQ button to purchase MP004319 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004319?
You can download the MP004319 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004319?
MULTICOMP PRO
