MULTICOMP PRO MP006215 Microswitch
This is a high-reliability snap action microswitch designed for precise switching applications in automotive, household appliances, and industrial equipment. Featuring SPDT contact form and various lever options, it offers a mechanical durability of over 1,000,000 cycles and electrical durability of at least 100,000 cycles. Its sealed IP67 enclosure ensures protection against dust and water ingress, making it suitable for harsh environments. Operating temperature range from -40°C to +85°C, with RoHS compliance, and a contact rating of 2A at 12V DC or 1A at 24V DC, the microswitch provides dependable performance for critical control functions.
MULTICOMP PRO MP006215 Microswitch Specifications:
- Contact Rating: 2A at 12V DC / 1A at 24V DC
- Mechanical Durability: 1,000,000 cycles minimum
- Electrical Durability: 100,000 cycles minimum
- Contact Resistance: 150mΩ max
- Insulation Resistance: 100MΩ min (at 500V DC)
- Dielectric Strength: 600V AC between terminals
- Operating Temperature: -40°C to +85°C
- Sealing: IP67
- Contact Form: SPDT
- Various lever options available
- Operating Force: 50gf (0.5N) to 75gf (0.75N)
- Total Travel: 5.1mm to 9.5mm depending on model
- Operating Position: approximately 6.4mm to 11.2mm
- Rated Voltage: 12V DC or 24V DC resistive load
Buy the Buy multicomp Pro Microswitch Part Number MP006215 Online
Experience reliable and precise switching with the multicomp Pro microswitch MP006215, suitable for automotive, household, and industrial applications. Its IP67-sealed enclosure ensures protection against dust and water ingress, making it ideal for harsh environments. Rated at 2A at 12V DC, with a long mechanical lifespan of over 1 million cycles, this SPDT switch offers excellent performance under extreme temperature conditions from -40°C to +85°C. Easy to install with various lever options, it ensures long-lasting, dependable operation in critical control systems.
Get multicomp Pro microswitch MP006215 today—designed for durability in automotive and household control applications.
