MULTICOMP-PRO MP700677 Digital Storage Oscilloscope
This handheld digital storage oscilloscope provides versatile measurement capabilities with bandwidth options of 20MHz and 60MHz, a 3.7-inch color TFT display, and multi-function features such as auto-scale, FFT analysis, waveform recording, and replay. It supports single channel input with a USB interface for data transfer, and includes a rechargeable Li-ion battery offering up to 6 hours of operation. Designed for portability, it is ideal for troubleshooting electronic circuits, educational purposes, and field testing in a compact, lightweight case.
MULTICOMP-PRO MP700677 Digital Storage Oscilloscope Specifications:
- Bandwidth: 20MHz / 60MHz
- Sample Rate: 500MS/s
- Display: 3.7" colour TFT (640 x 480 pixels)
- Channel: Single
- Input Impedance: 1MO. + 2%, in parallel with 18pF / 15pF + 5pF
- Record Length: 24K points
- Probe Attenuation: 1X, 10X, 100X, 1000X
- Input Coupling: DC, AC, GND
- Vertical Sensitivity: 5mV/div ~ 5V/div
- Vertical Resolution: 8 bits
- Max Input Voltage: 400V (PK - PK)
- Trigger Type: Edge, Video
- Trigger Mode: Auto, Normal, Single
- Waveform Storage: 4 waveforms
- Communication: mini-USB, mini-RS232
- Battery: Li-ion, 6 hours backup
- Dimensions: 115mm x 180mm x 40mm
- Weight: 645g
- Power Supply: 100V - 240V AC
- Standard Accessories: Power cord, USB cable, manual, probes, probes adjust tool, multimeter leads, adapter, soft bag
Buy the Buy multicomp Handheld Oscilloscope Part Number MP720014 EU-UK Online
Purchase the multicomp handheld digital storage oscilloscope with 20 or 60MHz bandwidth today online. Its lightweight design, waveform recording, FFT analysis, and USB data transfer make it perfect for troubleshooting, field testing, and educational use. Equipped with a 3.7-inch color TFT display and rechargeable Li-ion battery, it offers up to 6 hours of continuous operation. Its multi-function capabilities include auto-scale, trigger options, waveform storage, and real-time sampling at 500MS/s, delivering accurate and versatile electronic measurements in a compact form.
Order your multicomp series MP720014 handheld oscilloscope today and experience reliable portable testing with 20MHz bandwidth and waveform recording capabilities.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MP700677?
You can click on the BUY or RFQ button to purchase MP700677 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MP700677?
You can download the MP700677 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MP700677?
MULTICOMP-PRO
