MULTICOMP-PRO MPM12SWS4AFP industrial M12 cable assembly
This M12 cable assembly from the MPMIZ SW series features a durable IP67-rated design suitable for industrial environments. It includes a plug and receptacle with 4 sockets, a 0.5-meter wire length, and contact ratings up to 4A at 50V. The connectors are made of brass alloy with gold-over-nickel plating and polyamide housing for high durability. It supports over 100 mating cycles, features an FKM O-ring for sealing, and complies with IEC standards for pollution degree and temperature range from -25°C to +85°C, making it ideal for reliable industrial connectivity.
MULTICOMP-PRO MPM12SWS4AFP industrial M12 cable assembly Specifications:
- Connector: M12 plug and receptacle
- Wire Length: 0.5 meter
- Conductor Cross Section: 0.34mm² (3-5 contacts), 0.25mm² (8 contacts)
- Panel Thickness: 4mm
- Temperature Range: -25°C to +85°C IEC 60664-1
- IP Rating: IP67 IEC 60529
- Rated Voltage: 50V (3-4 contacts), 50V (5 contacts), 30V (8 contacts)
- Rated Current: 4A (3-4 contacts), 4A (5 contacts), 2A (8 contacts)
- Material: Brass alloy, Polyamide housing
- Contact Plating: Au over Ni
- Housing Plating: Ni over Cu
- Volume Resistance: 8mΩ
- Mating Cycles: >100 IEC 60512-9A
- Pollution Degree: 3 IEC 60664-1
- Sealing: FKM O-ring
Buy the Aecoded MPMIZ SW series – Reliable M12 Cable Assembly for Industrial Applications
Purchase the Aecoded MPMIZ SW series 4-pin M12 cable assembly online today and ensure reliable connection for your industrial automation needs. Designed with durable brass alloy connectors and gold-over-nickel plating, this 0.5-meter cable offers excellent electrical performance and long-term durability. Suitable for harsh environments with a protection rating of IP67, it supports over 100 mating cycles, ensuring high reuse and reliability. Perfect for sensors, automation equipment, and industrial control systems, providing secure and sealed connections in demanding applications.
Get Aecoded MPMIZ SW series 4-pin cable assembly today—built for industrial automation and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MPM12SWS4AFP?
You can click on the BUY or RFQ button to purchase MPM12SWS4AFP from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MPM12SWS4AFP?
You can download the MPM12SWS4AFP datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MPM12SWS4AFP?
MULTICOMP-PRO
