MULTICOMP PRO PP000945 Welding Cable
This welding cable is designed for industrial use in automated and manual welding applications, such as automotive assembly lines and shipyards. It features a durable rubber sheath resistant to oils, acids, and heat, with flexible copper conductors complying with BS EN 60228 standards. Suitable for high current loads with a voltage rating of 100V and operating temperature from -40°C to +85°C. Its construction includes polyester tape separation and rubber insulation, ensuring reliable performance under demanding conditions. Available in black and red, with various core sizes tailored for different welding processes.
MULTICOMP PRO PP000945 Welding Cable Specifications:
- Voltage Rating: 100V
- Temperature Rating: -40°C to +85°C (Fixed), -20°C to +85°C (Flexed)
- Conductor: Class 6 flexible copper according to BS EN 60228
- Construction: Copper conductor, PET separator, rubber sheath (Type EMS BS EN 50363)
- Max. Bending Radius: 6 x overall diameter
- Sheath Colour: Black & Red
- Nominal Cross-Sectional Area: 10 mm², 16 mm², 25 mm², 35 mm²
- Insulation Thickness: 2 mm
- Dimensions vary by size, from approximately 146 mm to 384 mm in length per reel
- Max. Resistance of conductors: 0.21 Ω at 20°C for sizes 10 mm², 16 mm², 25 mm², 35 mm²
- Applicable to welding processes: Fully automatic, semi-automatic, manual, and occasional welding
- Duty cycle: Ranges from 20% to 100%, based on application
- Overall weight: 146 g/km to 384 g/km depending on size
Buy the Multicomp Pro PP000945 – Reliable Welding Cable for Industrial Applications
Purchase the Multicomp Pro welding cable now and enjoy a robust, flexible, and durable solution suitable for various industrial welding applications. This high-quality cable features a rubber sheath resistant to oils, acids, and extreme temperatures, with copper conductors compliant with BS EN standards. Its versatile sizes support different welding processes, from automatic to manual, ensuring optimal current capacity and reliable performance. Order online today to benefit from fast delivery, competitive pricing, and trusted quality for your industrial welding needs.
Buy Multicomp Pro PP000945 welding cable now and experience unmatched reliability and performance in heavy-duty industrial welding tasks.
