MULTICOMP PRO PP002170 Twin and Earth LSZH Cable
This twin and earth LSZH cable is designed for safe installation in walls, on boards, or embedded in plaster, offering fire, smoke emissions, and toxic fume resistance. With cross-linked polyethylene insulation and low smoke zero halogen sheath, it complies with BS 7211 and IEC standards. Suitable for use in both residential and industrial settings, it features solid and stranded copper conductors ranging from 1mm² to 10mm². This cable provides excellent electrical performance with current capacities up to 44 amps and minimal voltage drops, ensuring reliable, safe, and RoHS-compliant wiring solutions.
MULTICOMP PRO PP002170 Twin and Earth LSZH Cable Specifications:
- Voltage Rating: 300/500V
- Temperature Rating: -5°C to +70°C
- Minimum Bending Radius: 3 x overall diameter
- Core Identification: Brown, Blue, White
- Sheath Material: LSZH (Low Smoke Zero Halogen) Type LTS2
- Insulation Material: XLPE (Cross-Linked Polyethylene) Type GP8
- Conductor Material: Copper (solid for 1mm²-2.5mm², stranded for 4mm²-10mm²)
- Conductor Resistance at 20°C: 1mm² - 18.1 Ω/km, 1.5mm² - 12.1 Ω/km, 2.5mm² - 7.41 Ω/km, 4mm² - 4.61 Ω/km, 10mm² - 1.83 Ω/km
- Current Capacity: Up to 44 Amps, depending on cross-sectional area and installation method
- Standards Compliance: BS 7211, IEC 60754-1, IEC 60754-2, IEC 61034, BS EN/IEC 60332-1-2
- Cable Length Options: 100 meters or per meter
- Part Numbers: PP002170 (1mm²), PP002171 (1.5mm²), PP002172 (2.5mm²), PP002173 (4mm²), PP002174 (6mm²), PP002175 (10mm²)
Buy the Multicomp RoHS Twin and Earth LSZH Cable – Reliable Electrical Wiring for Industrial Applications
Enhance your electrical installations with our twin and earth LSZH cable, offering fire-resistant, low smoke, halogen-free performance suitable for walls, channels, and embedded applications. Available in various sizes, it complies with BS 7211 and international standards, providing safe, reliable, and RoHS-compliant wiring solutions. Perfect for residential, commercial, and industrial settings where safety and performance are paramount. Purchase online today to enjoy fast delivery, competitive prices, and trusted quality for your electrical projects.
Order your Multicomp Series PP002170 twin and earth LSZH cable today and ensure your electrical installations are safe, compliant, and reliable.
