MULTICOMP PRO RBM310RAVB Signal Switch
The RBM310RAVB is a high-quality flat-head and cross-head SMT actuator designed for precision signal switching in electronic devices. Constructed with durable thermoplastic nylon and high-temperature components, it features a 10-step rotating actuation mechanism. Rated for a non-switching current of 24V DC 400mA and switching of 24V DC 150mA, it supports up to 10,000 operation cycles. The device withstands temperatures from -60°C to +125°C, with excellent dielectric strength and low contact resistance, making it ideal for various automation and control applications.
MULTICOMP PRO RBM310RAVB Signal Switch Specifications:
- Rating: Non Switching: 24V DC 400mA, Switching: 24V DC 150mA
- Life: 10,000 Steps
- Operating Force: Max. 400gf.cm
- Initial Contact Resistance: Max. 100mΩ
- Dielectric Strength: AC 250V 1min
- Insulation Resistance: Min. 100MQ at DC 250V
- Operating Temperature: -60°C to +125°C
- Storage Temperature: -60°C to +125°C
- Material: Thermoplastic Nylon, FR-4 PCB, Stainless Steel Spring, Brass Terminals
- Dimensions: Millimeters provided in diagram, typical size approximations
- Soldering Profile: Max 260°C, 60-150 sec, up to 2 reflow cycles
- Vibration & Shock: MIL-STD-202F compliant, 10-55Hz vibration, 50G shock
- Operation Force: Max. 400gf.cm, 10,000 cycles durability
- Temperature Range: -60°C to +125°C for operational and storage conditions
- Lead-Free Solder Compatibility: Yes, with appropriate profile
- Component Type: Rotary Signal Switch, Control Component
Buy the Buy Multicomp Pro RBM310RAVB Part Number RBM310RAVB Online
Enhance your electronic design with the reliable Multicomp Pro RBM310RAVB signal switch. Featuring a durable nylon base, high-temperature components, and a 10,000 cycle life, this rotary actuator ensures precise control in automation projects. Rated for 24V DC 150mA switching and 400mA non-switching, it withstands extreme temperatures from -60°C to +125°C. Easy to solder with recommended profiles and MIL-STD vibration and shock resistance, it offers consistent performance for industrial, control, and automation applications. Buy online today for quality and durability.
Get Multicomp Pro RBM310RAVB today—built for precision and long-lasting durability in signal switching applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO RBM310RAVB?
You can click on the BUY or RFQ button to purchase RBM310RAVB from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part RBM310RAVB?
You can download the RBM310RAVB datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of RBM310RAVB?
MULTICOMP PRO
