MULTICOMP PRO SBR2512 Three Phase Bridge Rectifier
This silicon passivated three-phase bridge rectifier is designed for high-current applications, offering low forward voltage drop and high surge current capability. Encased in an epoxy case with a heatsink mounting surface, it ensures high reliability and efficient heat transfer. Suitable for resistive or inductive loads, it features plated solderable leads, robust thermal characteristics, and a wide operating temperature range from -55°C to +160°C. Ideal for industrial power conversion, it provides high surge currents and excellent electrical performance in a compact form factor.
MULTICOMP PRO SBR2512 Three Phase Bridge Rectifier Specifications:
- Peak Repetitive Voltage VRRM: 50V to 1600V depending on model
- Working Peak Reverse Voltage VRWM: up to 1600V
- Peak Non-Repetitive Reverse Voltage VrsM: 75V to 1700V
- Max RMS Reverse Voltage Vriaws: 35V to 1120V
- Average Forward Current: 25A
- Peak Forward Surge Current: 375A at 60Hz
- Forward Voltage Drop: 1.4V at 12.5A/17.5A
- Thermal Resistance Junction to Case: 1.42KW
- Operating Temperature Range: -55°C to +160°C
- Storage Temperature Range: -55°C to +160°C
- RMS Isolation Voltage from Case to Lead: 2,500V
- Mounting: Bolt down on heatsink with thermal compound, max torque 20 in.lbs.
- Dimensions: approximately 23.8 mm diameter, length depends on model
- Weight: 20 grams approximately
Buy the Buy Multicomp Series SBR2512 Part Number SBR2512 Online
Get your Multicomp Series SBR2512 three-phase bridge rectifier online today for efficient power rectification. Designed for high current, low voltage drop, and robust thermal management, this product ensures reliable operation in demanding industrial environments. Perfect for converting AC to DC in motor drives, power supplies, and industrial automation systems, it features high surge current capacity, easy mounting, and excellent electrical performance. Purchase now for quick delivery and dependable power conversion solutions.
Order your Multicomp Series SBR2512 high-current bridge rectifier today and ensure reliable power conversion for your industrial projects.
