MULTICOMP PRO SIP04T 4 Way SIL Switch
This 4-way SIL switch from Multicomp Pro offers reliable performance with a durable construction suitable for various electronic applications. Featuring four positions with a compact DIP and SIP mount, it has a contact current rating of up to 100mA DC and a dielectric strength of 300V AC for safe operation. The switch's actuation is via a flush slide actuator, made from high-temperature thermoplastic in black and white options with gold-plated alloy copper contacts. Its operating temperature ranges from -30°C to +80°C, supporting robust performance across different environments. Ideal for industrial and electronic projects, it ensures low contact resistance and high insulation resistance, meeting RoHS compliance.
MULTICOMP PRO SIP04T 4 Way SIL Switch Specifications:
- Switch Type: DIP, SIP
- Contact Configuration: SPST-CO (Single Pole Single Throw - Make) with 14 positions
- Pitch Spacing: 2.54mm
- Contact Current DC Max: > 100mA
- Switch Mounting: Through Hole, SMD
- Actuation Type: Flush Slide
- Actuator Type: Flat
- Contact Material: Alloy Copper
- Contact Plating: Gold
- Dielectric Strength: 300V AC / 1 minute
- External Depth: 3.2mm
- External Width: 12.7mm
- Height: 5mm
- No. of Electrical Operations: 500
- Operating Force: 7.84N
- Operating Temperature: -30°C to +80°C
- Pin Configuration: 12.7mm
- Series: SIL
- Terminal Plating: Tin
- Terminal Type: SMD
- Insulation Resistance: 100MQ Min. 500V DC
- Circuit: SPST
- Contact Resistance: (a) 100mΩ max. at initial, (b) 200mΩ max. after life test
- RoHS Compliant: Yes
- Soldering Process: Wave soldering at 500°F (260°C) Max. 5s; Hand soldering with 30W iron at 350°C Max. 5s
Buy the Multicomp Series SIL 4 Way Switch: SIP04T
Shop the high-quality 4 way SIL switch from Multicomp Pro online today. Designed with durable thermoplastic and gold contacts, it ensures seamless operation in industrial and electronic applications. With a compact DIP and SIP mount, it offers excellent electrical performance, low contact resistance, and high insulation resistance. Suitable for various projects, it supports operating temperatures from -30°C to +80°C and complies with RoHS standards. Buying online guarantees fast delivery, reliable customer service, and genuine products for your electronics needs.
Order your Multicomp Series SIL 4 Way Switch SIP04T today and ensure reliable connectivity in your electronic projects with high durability and performance.
