MULTICOMP PRO SMCJ36CA Transient Voltage Suppressor
The SMCJ36CA transient voltage suppressor is a unidirectional TVS diode designed to protect electronic circuits from voltage spikes and surges. It features a glass passivated junction, rapid response time, and high peak pulse power capability of 1500W with a 10/1000us waveform. The device is capable of withstanding peak pulse currents and surge incidents, offering reliable overload protection for sensitive electronic components. Its rugged construction includes UL 94V-0 rated epoxy, making it suitable for high-temperature soldering and harsh environments. Ideal for diverse industrial and electronic applications requiring efficient transient suppression.
MULTICOMP PRO SMCJ36CA Transient Voltage Suppressor Specifications:
Peak power dissipation: 1500W with 10/1000us waveform
Maximum pulse current: 200A (uni-directional)
Peak forward surge current: 200A for 8.3ms
Junction temperature range: -55°C to +150°C
Thermal resistance, junction to ambient: 100°C/W
JEDEC DO-214AB case, glass passivated junction
Polarity: Unidirectional with cathode marked by color band
Flammability rated UL 94V-0 epoxy, high-temperature soldering capable at 250°C/10s
Weight: 0.21 grams
Dimensions and case specifics: Molded plastic over glass passivated junction, dimensions in millimeters
Buy the Buy Manufacturer Transient Voltage Suppressor Part Number SMCJ36CA Online
Secure your electronic systems with the Manufacturer SMCJ36CA transient voltage suppressor, a high-performance protection device capable of handling 1500W peak pulse power. Featuring rapid response time and rugged construction, including UL 94V-0 rated epoxy, it is ideal for safeguarding sensitive components against voltage spikes and surges. Suitable for high-temperature soldering at 250°C/10s, this device ensures reliable performance in harsh environments. Order online today and give your projects dependable transient surge protection for maximum reliability and safety.
Order your Manufacturer SeriesSMCJ36CA transient voltage suppressor today and enhance your circuit's surge protection with high reliability and quick response.
