MULTICOMP PRO SPC21450 Female Audio Receptacle
The Female XLR Audio Receptacle is a high-quality, panel-mount connector designed for professional audio applications. It features a zinc die-cast housing with a black finish, a grey PPT insulator, and a gold-plated phosphorus bronze socket. Rated for 15A at 125VAC, it ensures reliable, low-resistance connections with a contact resistance of 5mΩ max. The component can operate from -55°C to +70°C, making it suitable for various environments. Its durable construction and RoHS compliance make it ideal for professional audio and broadcasting equipment, ensuring long-lasting performance.
MULTICOMP PRO SPC21450 Female Audio Receptacle Specifications:
- No. of Contacts: 3
- Gender: Receptacle
- Connector Mounting: Panel Mount
- Contact Rating: 15A@ 125VAC
- Contact Resistance: 5mΩ max.
- Insulation Resistance: 5000MΩ min @ 500V DC
- Dielectric Strength: 1400 VAC
- Capacitance: 4pF max.
- Insertion Force: 1.0 ~8.0kg
- Withdrawal Force: 1.0 ~8.0kg
- Operating Temperature: -55°C to +70°C
- Housing: Zinc Die Cast; Black Finish
- Insert Insulator: PPT, Grey
- Socket Material: Phosphor Bronze, Gold Plated
- RoHS Compliant
Buy the Multicomp Series Female Audio Receptacle: SPC21450
Order the Female Audio Receptacle today for professional audio setups. Featuring a durable zinc die-cast housing, gold-plated socket, and rated for 15A at 125VAC, it ensures reliable, low-resistance connections in various environments. Suitable for broadcast, stage, and studio use, this RoHS-compliant connector delivers high performance and longevity. Its panel mount design simplifies installation, while its robust construction withstands demanding conditions. Purchase online now to experience seamless audio connectivity with this high-quality, long-lasting XLR receptacle designed for professional audio equipment.
Get Multicomp Series Female Audio Receptacle SPC21450 today—built for reliable professional audio connections and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SPC21450?
You can click on the BUY or RFQ button to purchase SPC21450 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SPC21450?
You can download the SPC21450 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SPC21450?
MULTICOMP PRO
