MULTICOMP MC002546 power supply
This 5.1V AC-DC power supply delivers 212.75W output power with an efficiency of 81%. Designed for reliable industrial applications, it features universal input voltage of 90-264 VAC, low no-load power consumption of 75 mW, and provides robust safety and EMC approvals including UL, TUV, and CE standards. The power supply has a compact size, built-in protection with auto-restart short circuit feature, and a 3-year warranty, making it suitable for industrial, automation, and control systems requiring stable, efficient power conversion.
MULTICOMP MC002546 power supply Specifications:
- Output Power: 212.75W
- Output Voltage: 5.1V
- Output Current: 2500mA
- Efficiency: 81%
- Input Voltage: 90 - 264 VAC
- Input Frequency: 47 - 63 Hz
- Inrush Current: 50 A at 240V AC, cold start
- Total Regulation: 5%
- Ripple & Noise: 100 mV pk-pk
- Protection: Auto re-tore short circuit, internal fuse
- Isolation: 3000 VAC
- Operating Temperature: -20°C to +40°C
- Storage Temperature: -20°C to +85°C
- Operating Humidity: 5% - 93%
- Weight: 0.22 lbs (100 g)
- Certifications: UL60950-1, EN60950-1, IEC60950-1, Level VI efficiency
- Dimensions: Approx. 2.22 x 1.91 x 0.87 inches (56.4 x 48.4 x 22.2 mm)
Buy the Multicomp MC002546 – Reliable Power Supply for Industrial Applications
Secure your industrial or automation project with the high-quality multicomp power supply MC002546. Designed for stability and efficiency, it provides 5.1V at 2500mA, certified for safety and EMC compliance. With features like auto-restart short circuit protection, wide input voltage range, and a 3-year warranty, this power supply ensures reliable operation in demanding environments. Easily order online today and guarantee your equipment has the stable power it needs for optimal performance and longevity.
Order your Multicomp SeriesMC002546 power supply today and ensure your projects benefit from dependable, efficient power conversion and safety compliance.
Frequently Asked Questions
Where can I buy MULTICOMP MC002546?
You can click on the BUY or RFQ button to purchase MC002546 from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part MC002546?
You can download the MC002546 datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of MC002546?
MULTICOMP
