MURATA POWER SOLUTIONS 48470SC Shielded Power Inductor
The 4800S series comprises shielded, surface-mount power inductors designed for switching power supplies and power line filters. These inductors feature a bobbin wound design, high saturation currents, and an integral ferrite shield to reduce EMI. Suitable for compact, high-current applications, they are RoHS compliant, UL 94V-0 rated, and support reflow soldering. The series covers inductance values from 1.0 µH to 470 µH, with maximum DC currents up to 900 A. Their small size, surface-mount format, and EMI shielding make them ideal for modern electronics requiring high efficiency and reliability.
MURATA POWER SOLUTIONS 48470SC Shielded Power Inductor Specifications:
- Inductance Range: 1.0 µH to 470 µH
- Maximum DC Current: Up to 900 A depending on model
- DC Resistance: As specified per model, e.g., 0.76Ω for 470 µH
- Saturation Current: Up to 45 A typical at 25°C
- SRF (Self-Resonant Frequency): Up to 630 MHz
- Q Factor: Up to 36 depending on model
- Operating Temperature Range: -40°C to 85°C
- Storage Temperature Range: -40°C to 125°C
- Peak Reflow Solder Temperature: 245°C
- Pin Finish: Tin
- RoHS Compliant, UL 94V-0 materials
- Package Type: Surface mount, bobbin wound with EMI shield
- Reel Packaging: Yes
- Dimensions: Length varies with model, typical size approx. 13.5x13.5 mm
- Compliance: RoHS, UL listed
- Materials: Ferrite core, tin-plated leads
Buy the Murata 48470SC – Reliable Shielded Power Inductors for Industrial Applications
Purchase Murata 48470SC inductors online now to ensure high performance in switching power supplies and EMI filtering. Designed for compact applications, these shielded surface-mount inductors provide high saturation currents and excellent EMI reduction. Perfect for industrial and electronic devices, they are RoHS compliant and suitable for reflow soldering processes. Featuring a robust ferrite shield, these inductors enhance reliability and efficiency in demanding environments. Order today to benefit from fast shipping, quality assurance, and technical support for your high-current power supply needs.
Get Murata 48470SC today—built for high current, reliable power filtering, and EMI reduction in industrial electronics.
Frequently Asked Questions
Where can I buy MURATA POWER SOLUTIONS 48470SC?
You can click on the BUY or RFQ button to purchase 48470SC from an authorized MURATA POWER SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 48470SC?
You can download the 48470SC datasheet or visit the MURATA POWER SOLUTIONS website for support.
Who is the manufacturer of 48470SC?
MURATA POWER SOLUTIONS
