Microchip Technology MCP1700T5002ETT Low Dropout Voltage Regulator
The MCP1700T-5002E/TT is a 5V fixed output CMOS low-dropout (LDO) linear voltage regulator. It can supply up to 250mA of current with an extremely low dropout voltage of 178mV at 250mA, making it highly efficient for battery-powered applications. This device features a low quiescent current of only 1.6µA, ensuring minimal power consumption, and maintains high output voltage accuracy within ±0.4%. It is stable with a 1.0µF ceramic output capacitor and allows high current output in small packages with minimal input-to-output voltage differential. Integrated short-circuit and over-temperature protection enhance its reliability. Suitable for portable devices, safety systems, consumer electronics, industrial applications, and power management systems.
Microchip Technology MCP1700T5002ETT Low Dropout Voltage Regulator Specifications:
- Output Voltage: 5.0V
- Output Current: up to 250mA
- Dropout Voltage: 178mV at 250mA
- Input Voltage Range: 2.3V to 6.0V
- Quiescent Current: 1.6µA
- Voltage Tolerance: ±0.4%
- Stable with: 1.0µF ceramic capacitor
- Protection: Short circuit and over-temperature
- Package: SOT-23, SOT-89, TO-92, 2x2 DFN-6
- Operating Temperature: -40°C to +125°C
Buy the Microchip MCP1700T5002E- Reliable 5V Voltage Regulator for Industrial Applications
Enhance your power management system with the Microchip MCP1700T-5002E/TT. This 5V CMOS low-dropout regulator delivers up to 250mA with an ultra-low dropout voltage of only 178mV at full load, ensuring efficient operation. Its low quiescent current of 1.6µA minimizes power consumption, ideal for battery-powered devices. The device is stable with a 1.0µF ceramic capacitor and incorporates safety features like short circuit and overtemperature protection. Perfect for portable electronics, industrial systems, and safety applications requiring high reliability and efficiency.
Buy Microchip MCP1700T-5002E/TT now and experience unmatched reliability and performance in your portable and industrial devices.
Frequently Asked Questions
Where can I buy Microchip Technology MCP1700T5002ETT?
You can click on the BUY or RFQ button to purchase MCP1700T5002ETT from an authorized Microchip Technology distributor.
How do I troubleshoot issues or seek technical support for part MCP1700T5002ETT?
You can download the MCP1700T5002ETT datasheet or visit the Microchip Technology website for support.
Who is the manufacturer of MCP1700T5002ETT?
Microchip Technology
