Microchip Technology TC4422CAT High-Speed MOSFET Driver
The TC4422 is a high-speed, high-current MOSFET driver capable of handling peak currents of 9A and continuous currents up to 2A. It operates over a supply voltage range of 4.5V to 18V, features low output impedance, short propagation delay of 30ns, and fast rise/fall times. With noise immunity due to built-in hysteresis, it is suitable for driving large MOSFETs and IGBTs, line drivers, pulse generators, and motor controls. Its robust protection against electrostatic discharge and reverse currents makes it ideal for demanding power switching applications, with options available in various packages including DFN, PDIP, and SOIC.
Microchip Technology TC4422CAT High-Speed MOSFET Driver Specifications:
- Peak Output Current: 9A
- Continuous Output Current: 2A
- Supply Voltage Range: 4.5V to 18V
- Propagation Delay: 30 ns (typical)
- Rise/Fall Times: 30 ns / 180 ns (load-dependent)
- Output Impedance: 1.49 Ω (typical)
- Low Supply Current: 200 pA (logic ‘1’), 55 pA (logic ‘0’)
- Reverse Voltage Tolerance: Up to 5V negative input withstand
- Electrostatic Discharge Protection: Up to 4kV
- Package Types: 8-Pin DFN-S, PDIP, SOIC, TO-220
- Operating Temperature Range: 0°C to +125°C
- Thermal Resistance (DFN-S): 35.7 °C/W
- Package Material: Lead-free options available
- Control Input Compatibility: TTL, CMOS (3V to 18V)
- Application Suitability: Heavy load line drivers, pulse generation, motor control, switching large MOSFETs and IGBTs
Buy the Microchip Series TC442 High-Speed MOSFET Driver: TC4422CAT
Purchase the Microchip Series TC4422CAT high-speed MOSFET driver online today to equip your projects with dependable power switching components. Designed to handle up to 9A peak current and operate over a broad voltage range of 4.5V to 18V, this robust device features short propagation delays of 30ns, fast rise and fall times, and excellent electrostatic protection. Whether you're developing motor controllers, line drivers, or pulse generators, the TC4422 offers unmatched performance, low noise immunity, and versatile package options including DFN, PDIP, and SOIC, ensuring seamless integration into your system.
Order your Microchip Series TC4422CAT high-current MOSFET driver today and ensure reliable power switching for demanding industrial applications.
