NKK Switches KP0215ANBKG03RGBP RGB Pushbutton
The KP Series miniature RGB pushbuttons are compact switches equipped with vibrant, super bright RGB LEDs providing full color spectrum and customizable legends. Designed for broadcast and audio/video applications, they feature a long total travel of 4.5mm or shorter stroke of 3.5mm, with tactile, nontactile, or tactile/audible actuation options. Made with durable polyacetal housing, gold-plated contacts, and tested for high reliability with a minimum of 5,000,000 operations. Ideal for logic-level circuits, these switches meet UL standards and are suitable for precise control in professional multimedia setups.
NKK Switches KP0215ANBKG03RGBP RGB Pushbutton Specifications:
- Electrical Capacity: 100mA max @ 12V DC
- Contact Resistance: 200 milliohms max
- Insulation Resistance: 100 megohms minimum @ 250V DC
- Dielectric Strength: 1,000V AC between contacts; 1,500V AC between contacts and case
- Mechanical Life: 5,000,000 operations minimum
- Travel: 4.5mm (KPO1) or 3.5mm (KPO2)
- Actuation Force: 1.9N (KPO1), 1.6N (KPO2)
- Housing Material: Polyacetal, UL94V-0 glass fiber reinforced PBT
- Plunger Lengths: 9.2mm for 12.0mm cap, 15.0mm & 17.4mm for larger caps
- Operating Temperature: -25°C to +50°C
- Humidity Resistance: 90-95% for 240 hours at 40°C
- Vibration: 10-55Hz, peak-to-peak 1.5mm over 1 minute
- Shock: 51G acceleration in 6 directions
- Soldering: Wave (preheat 140°C, peak 270°C), manual (410°C for 4 sec)
- Standards: Not UL or CSA certified but designed for low-voltage, low-current applications.
Buy the NKK Series KP RGB Pushbuttons: KP0215ANBKG03RGBP
Experience the reliability and vibrant LED illumination of the NKK KP RGB Pushbuttons. Perfect for control panels, broadcast systems, and multimedia applications, these compact switches offer customizable legends, multiple actuation options, and a robust design rated for 5 million operations. Easy to install with a sleek profile, they ensure precise circuit control with high durability. Order online now and enhance your systems with these versatile, high-quality RGB switches engineered for professional use and long-term performance.
Get NKK KP0215ANBKG03RGBP today—built for precision, vibrant RGB LED illumination, and long-lasting durability in multimedia controls.
Frequently Asked Questions
Where can I buy NKK Switches KP0215ANBKG03RGBP?
You can click on the BUY or RFQ button to purchase KP0215ANBKG03RGBP from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part KP0215ANBKG03RGBP?
You can download the KP0215ANBKG03RGBP datasheet or visit the NKK Switches website for support.
Who is the manufacturer of KP0215ANBKG03RGBP?
NKK Switches
