NKK Switches LB26WGG01 Waterproof Pushbutton Switch
The LB26WGG01 series is a standard size illuminated waterproof pushbutton switch designed for rugged industrial and outdoor environments. It features a robust construction with IP65 sealing compliance, making it suitable for harsh conditions. The switch incorporates a bright LED illumination with color options for clear visual indication. It offers a snap-action contact mechanism for long life and reliable operation, with quick connect terminals to facilitate installation. The switch housing is available in black with stainless steel clips ensuring secure mounting across various panel thicknesses. Ideal for control panels requiring reliable, sealed actuation with visual feedback.
NKK Switches LB26WGG01 Waterproof Pushbutton Switch Specifications:
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- Sealing Standard: IP65 of IEC60529 (similar to NEMA 4 & 13)
- Electrical Capacity: 3A @ 125V AC or 3A @ 250V AC; 0.4VA max @ 28V AC/DC
- Mechanical Life: 1,000,000 operations
- Electrical Life: 200,000 operations
- Operating Temperature Range: -25°C to +50°C (Illuminated), -25°C to +70°C (Non-illuminated)
- Dimensions: Suitable panel thickness 1.0mm to 4.0mm, recommended panel cutout 22.0mm diameter
- Mounting: Stainless steel clips for secure attachment
- LED Colors: Red, Amber, Green, White, Blue
- Contact Resistance: 50 milliohms maximum for silver contacts
- Vibration: 10-55Hz with peak-to-peak amplitude of 1.5mm
- Shock Resistance: 50G acceleration in all directions
- Solder & Quick Connect Terminals: Epoxy sealed to prevent contamination
Buy the NKK LB26WGG01 – Reliable Waterproof Pushbutton for Industrial Applications
Order the NKK LB26WGG01 waterproof illuminated pushbutton switch online today and benefit from its IP65 sealing, bright LED indicators, and durable construction. Perfect for industrial control panels needing reliable operation in outdoor or wet conditions. Easy to install with quick connect terminals and secure mounting clips, this switch offers long mechanical and electrical life, making it ideal for demanding applications. Enhance your control solutions with this robust, sealed pushbutton designed for global industry standards and outdoor use.
Buy NKK LB26WGG01 waterproof illuminated switch now and experience unmatched reliability and performance in harsh industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches LB26WGG01?
You can click on the BUY or RFQ button to purchase LB26WGG01 from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part LB26WGG01?
You can download the LB26WGG01 datasheet or visit the NKK Switches website for support.
Who is the manufacturer of LB26WGG01?
NKK Switches
