NKK Switches S7AWF Industrial Toggle Switch
The S7AWF toggle switch offers a reliable standard size solution with medium to high electrical capacity, ideal for industrial and electronic applications. Featuring single pole with quick connect terminals, it supports resistive loads up to 15A and inductive loads up to 8A at 125V AC. Its robust construction includes a zinc-plated steel housing, phenolic resin insulator, and chrome-plated brass terminals, ensuring durability in various environmental conditions. Suitable for panel mounting with a maximum panel thickness of 0.158 inches (4.0mm) and rated for 30,000 to 50,000 mechanical operations, it complies with UL and CSA standards.
NKK Switches S7AWF Industrial Toggle Switch Specifications:
- Electrical Capacity: Resistive 15A at 125V, 6A at 250V, 8A at 30V DC; Inductive 8A at 125V, 6A at 250V, 8A at 30V DC
- Pole & Keyway: Single pole, with quick connect terminals
- Mechanical Life: 30,000 operations minimum
- Material: Steel with zinc plating, phenolic resin insulator, chrome-plated brass terminals
- Maximum Panel Thickness: 0.158 inches (4.0mm)
- Operating Temperature Range: -10°C through +70°C (14°F through +158°F)
- Standards & Certifications: UL Recognized, CSA Certified
- Mounting Torque: 1.47 Nm (13 in-lbf) for single nut
- Soldering & Installation: Manual soldering, suitable for panel mounting with specified torque
Buy the NKK Series S Toggle Switch: S7AWF
Purchase the NKK Series S7AWF toggle switch online now and ensure your projects benefit from high-capacity durability and certified performance. Designed for industrial use, this reliable switch features quick connect terminals, a zinc-plated steel housing, and phenolic insulator for long-term durability. Suitable for panel mounting up to 0.158 inches thick, it offers up to 50,000 mechanical cycles, making it an ideal component for various electronic and industrial control systems. Order today for fast delivery and trusted performance.
Order your NKK Series S7AWF toggle switch today and give your projects the dependable quality they deserve for reliable industrial switching.
Frequently Asked Questions
Where can I buy NKK Switches S7AWF?
You can click on the BUY or RFQ button to purchase S7AWF from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part S7AWF?
You can download the S7AWF datasheet or visit the NKK Switches website for support.
Who is the manufacturer of S7AWF?
NKK Switches
