NKK Switches UB15KKW015F Low Profile Pushbutton
Low profile pushbuttons designed for compact applications, featuring illuminated LEDs available in multiple colors. These switches provide reliable switching performance with gold or silver contacts rated for 5A at 125/250V AC. They have quick-make, quick-break keylocks for sensitive actuation, and rugged housing materials with UL94V-0 flammability rating. The switches support both momentary and alternate circuits, with high mechanical and electrical life ratings. Suitable for panel mounting, they offer tailored legends, optional accessories, and are recognized for UL and CSA certifications, ensuring safe, durable operation in various industrial and control systems.
NKK Switches UB15KKW015F Low Profile Pushbutton Specifications:
- Electrical Rating: 5A at 125/250V AC, 0.4VA max at 28V AC/DC
- Contact Resistance: Silver 50 milliohms max, Gold 100 milliohms max
- Insulation Resistance: Minimum 200 megaohms @ 500V DC
- Dielectric Strength: 1,000V AC between contacts, 1,500V AC between contacts and case
- Mechanical Life: 1,000,000 operations for momentary, 200,000 for alternate action
- Electrical Life: 100,000 operations for resistive load
- Nominal Operating Force: 1.9N for square and rectangular poles
- Pretravel: 0.067” (1.7mm); Overtravel: 0.024” (0.6mm); Total Travel: 0.091” (2.3mm)
- Housing Material: Glass fiber reinforced polyamide UL94V-0
- Ambient Temperature Range: -25°C to +50°C, non-illuminated -20°C to +70°C
- Soldering: Wave soldering and manual soldering profiles available
- Certifications: UL Recognized, CSA Certified (order with markings)
Buy the Buy NKK Switches Low Profile Pushbutton Part Number UB15KKW015F Online
Purchase NKK Switches UB15KKW015F online now to ensure seamless integration into your control systems. These compact, illuminated pushbuttons offer high durability, long cycle life, and safety certifications. Perfect for tight spaces, they feature LED indicators with vibrant colors like red, green, amber, and white, providing clear visual feedback. Their rugged construction with UL94V-0 housing material guarantees safety and longevity in industrial environments. Order today for fast shipping and restore reliable operation to your automation or control panel projects.
Get NKK Switches UB15KKW015F today—built for precision, durability, and reliable performance in control and automation applications.
Frequently Asked Questions
Where can I buy NKK Switches UB15KKW015F?
You can click on the BUY or RFQ button to purchase UB15KKW015F from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15KKW015F?
You can download the UB15KKW015F datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15KKW015F?
NKK Switches
