NKK Switches UB15SKW035C Low Profile Illuminated Pushbutton Switch
A low-profile illuminated pushbutton switch designed for professional electrical applications. Features a panel mount (PC) design with solder terminal connections for easy installation and reliable contact.
NKK Switches UB15SKW035C Low Profile Illuminated Pushbutton Switch Specifications:
- Poles & Circuits: Single Pole, SPDT
- Max Current: 5A at 125/250V AC, 0.4VA max @ 28V AC/DC
- Contact Resistance: 50 milliohms for silver, 100 milliohms for gold
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC contact-to-contact, 1,500V AC contact-to-case for 1 minute
- Mechanical Life: 1,000,000 operations for momentary, 200,000 for alternate action
- Electrical Life: 200,000 operations for resistive load of 3A @ 125V AC
- Nominal Operating Force: 1.9N (Square & Rectangular), 2.55N-3.1N (Double Pole)
- Travel: Pretravel 1.7mm, Overtravel 0.6mm, Total 2.3mm
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- Environmental: Operating temperature -20°C to +70°C, humidity 50G shocks, Vibration 1.5mm at 1.5Hz
- Soldering: Wave or manual soldering per Profile A in Supplement
- Certifications: UL, cULus, CSA (order with marking)
Buy the NKK Series UB UB15SKW035C: Low Profile Illuminated Pushbutton Switch
Upgrade your control system with the NKK Series UB low-profile illuminated pushbutton switch. Featuring PCB mount, solder terminals, and bright LED illumination options in various colors, this switch ensures easy installation and dependable performance. Designed for industrial and commercial applications, it offers high durability with a mechanical life of up to 1 million cycles and robust environmental resistance. Ideal for tight spaces, its lightweight and compact design makes it perfect for modern control panels. Purchase online now and enhance your project’s reliability and efficiency.
Order your NKK Series UB15SKW035C low-profile illuminated pushbutton switch today and equip your control panels with reliable, compact switching solutions.
Frequently Asked Questions
Where can I buy NKK Switches UB15SKW035C?
You can click on the BUY or RFQ button to purchase UB15SKW035C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15SKW035C?
You can download the UB15SKW035C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15SKW035C?
NKK Switches
