NKK Switches UB16VA001 Illuminated Control Button
The illuminated pushbutton with legend and protective guard is designed for industrial control panels, featuring a green LED indicator, clear polycarbonate lens, and a spring-loaded guard that opens 180° and closes automatically. It operates within -25°C to +50°C, with resistive load capacity of 5A at 125/250V AC or 30V DC. Made from UL94V-0 rated materials including glass-reinforced polyamide and stainless steel, it offers reliable electrical and mechanical performance, easy panel mounting, and environmental resilience for demanding applications.
NKK Switches UB16VA001 Illuminated Control Button Specifications:
- Color: Green LED indicator, clear polycarbonate lens with white legend
- Electrical Capacity: 5A at 125/250V AC, 5A at 30V DC
- Materials: Housing and bezel made from UL94V-0 rated glass fiber reinforced polyamide; guard from clear polycarbonate; spring from stainless steel
- Operating Temperature Range: -25°C to +50°C
- Vibration Resistance: 10-55Hz with peak-to-peak amplitude of 1.5mm
- Mechanical Life: Minimum 200,000 operations; Electrical Life: Minimum 100,000 operations at resistive load
- Pretravel: 0.067 in (1.7mm), Overtravel: 0.024 in (0.6mm), Total Travel: 0.091 in (2.3mm)
- Installation: Recommended panel thickness 0.039 to 0.106 in (1.0 to 2.7mm), snap-in mounting
- Environmental Resistance: Humidity 90-95% for 96 hours, vibration, shock
- Standards & Certifications: RoHS compliant, UL94V-0 rated for flammability
Buy the NKK Series UB Illuminated Pushbutton: UB16VA001
Order the NKK Series UB16VA001 illuminated pushbutton online today for your industrial control needs. Featuring a green LED indicator, sturdy UL94V-0 rated materials, and a spring-loaded guard, this switch ensures visibility and protection in demanding environments. Its construction includes glass-reinforced polyamide housing and stainless steel spring for long-lasting durability. Easy to install with snap-in mounting and operating effectively from -25°C to +50°C, it offers excellent electrical and mechanical performance, perfect for panel applications requiring reliability and safety.
Get NKK Series UB16VA001 illuminated pushbutton today—built for precision, durability, and reliable operation in industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches UB16VA001?
You can click on the BUY or RFQ button to purchase UB16VA001 from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB16VA001?
You can download the UB16VA001 datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB16VA001?
NKK Switches
