NKK Switches UB26RKW035D Low Profile Pushbutton Switch
This is a low-profile illuminated pushbutton switch compatible with PC mounting and soldering. It features a compact design suitable for various electronic applications, offering easy operation and reliable illumination.
NKK Switches UB26RKW035D Low Profile Pushbutton Switch Specifications:
- Poles & Circuits: Single Pole SPDT, Double Pole configurations available
- Electrical Capacity: 5A @ 125/250V AC, 0.4VA max @ 28V AC/DC
- Contact Resistance: Silver contacts max 50 milliohms; Gold contacts max 100 milliohms
- Insulation Resistance: Minimum 200 MΩ @ 500V DC
- Dielectric Strength: 1,000V AC between contacts, 1 minute; 1,500V AC between contacts and case, 1 minute
- Mechanical Life: Minimum 1,000,000 operations
- Electrical Life: 200,000 operations at resistive load of 3A @ 125V AC
- Operating Temperature Range: -20°C to +70°C
- Housing Material: UL94V-0 glass fiber reinforced polyamide
- Actuation Force: 1.9N (square & rectangular) for single pole
- Travel: Total 0.091" (2.3mm), Pretravel 0.067" (1.7mm), Overtravel 0.024" (0.6mm)
- Cap & LED Compatibility: Bright, super bright LEDs in various colors, full face or spot illumination
- Mounting Type: PCB Snap-in with bezel, panel mounting compatible
- Environmental Resistance: Humidity 95% for 96 hours at 40°C, Shock 50G, Vibration 3Hz-55Hz, amplitude 1.5mm
Buy the NKK Series UB Low Profile Pushbuttons: UB26RKW035D
Order the NKK UB26RKW035D low-profile illuminated pushbutton switch online today to benefit from quick shipping, trusted quality, and superior performance. This switch is ideal for space-saving applications, offering easy PCB mounting with soldering options, bright LED illumination in multiple colors, and long-lasting mechanical and electrical life. Perfect for control panels, automation, and electronic devices requiring durable, high-performance pushbuttons. Enhance your project today with this reliable, easy-to-install switch available for online purchase.
Buy NKK UB26RKW035D low-profile illuminated pushbutton switch now and experience unmatched reliability and performance in compact electronic designs.
