Nichicon UPW1V221MPD6TD Aluminum Capacitor
High-quality aluminum electrolytic capacitor designed for switching power supplies, offering low impedance, high reliability, and excellent performance over extended hours. Rated for voltages from 6.3V to 450V with capacitance values ranging from 0.47uF to 15000uF, it complies with RoHS and AEC-Q200 standards. Suitable for temperature ranges from -55°C to +105°C, ensuring stable operation under various conditions. Features include low leakage current, high ripple current capacity, and long endurance life of up to 8000 hours at 105°C, making it ideal for demanding electrical applications.
Nichicon UPW1V221MPD6TD Aluminum Capacitor Specifications:
- Category Temperature Range: -55°C to +105°C for 6.3 to 100V, -40°C to +105°C for 160 to 400V, -25°C to +105°C for 450V
- Rated Voltage Range: 6.3V to 450V
- Rated Capacitance Range: 0.47uF to 15000uF
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Leakage Current: Not more than 0.03CV or 4uA after 1 minute at rated voltage, whichever is greater
- Impedance (@ 20°C / 100kHz): 5x11mm: 0.60Ω, 4x7mm: 2.00Ω, 5x7mm: 0.95Ω, 8x15mm: 0.117Ω, 16x25mm: 0.022Ω, 18x40mm: 0.014Ω
- Ripple Current: Up to 2250mArms at 105°C / 120Hz, varying by size
- Endurance: 8000 hours at 105°C with specified ripple current
- RoHS and AEC-Q200 compliant standards
- Physical Size: Ranges from 4x7mm to 18x40mm, with detailed impedance specifications per size
Buy the Buy Nichicon Aluminum Electrolytic Capacitors Part Number UPW1V221MPD6TD Online
Purchase the Nichicon aluminum electrolytic capacitor today for your switching power supply needs. With its low impedance, long life, and high ripple current capacity, it guarantees optimal performance and durability. Compatible with RoHS and AEC-Q200 standards, rated for voltages up to 450V and temperatures from -55°C to +105°C, it’s suitable for demanding applications. Ensure your electrical systems run efficiently and reliably by ordering this premium capacitor online now, benefitting from fast shipping and authentic quality assurance.
Buy Nichicon UPW1V221MPD6TD high-reliability aluminum electrolytic capacitor now and experience unmatched performance in switching power supplies.
Frequently Asked Questions
Where can I buy Nichicon UPW1V221MPD6TD?
You can click on the BUY or RFQ button to purchase UPW1V221MPD6TD from an authorized Nichicon distributor.
How do I troubleshoot issues or seek technical support for part UPW1V221MPD6TD?
You can download the UPW1V221MPD6TD datasheet or visit the Nichicon website for support.
Who is the manufacturer of UPW1V221MPD6TD?
Nichicon
