OMEGA CN8DPT330 Temperature Controller
The CN8DPT Series is a versatile temperature and process controller featuring a bright 4-digit, 9-segment LED display with wide viewing angles. It supports multiple input types including thermocouples, RTDs, thermistors, and process signals, with scalable voltage/current inputs and a differential configuration. This model offers control modes such as ON/OFF and PID, auto-tuning with fuzzy logic, and up to 99 ramp and soak programs with individual event control. Its outputs include relays, SSR, DC pulse, and analog signals, with USB, optional Ethernet, and serial communication interfaces, all housed in a NEMA 1 enclosure with accurate measurement and robust safety certifications.
OMEGA CN8DPT330 Temperature Controller Specifications:
- Input Types: Thermocouple, RTD, thermistor, analog voltage, analog current, strain
- Input Ranges: Thermocouple K, J, T, E, R, S, B, C, N; RTD 100/500/1000, thermistor 2252 Q, 5K Q, 10K Q
- Output Types: Relay, SSR, DC pulse, analog voltage (0-10V), current (0-20mA)
- Display: 4-digit, 9-segment LED, 21 mm (0.83") height
- Control: ON/OFF, PID with auto-tune and fuzzy logic, ramp and soak up to 99 programs
- Communication: USB, optional Ethernet (RJ45), RS232/RS485, protocols including MODBUS
- Power Supply: 12 to 36 Vdc, 3 W; or 90-240 Vac, 4 W
- Dimensions: 48 H x 48 W x 127 mm D (1.89 x 1.89 x 5")
- Enclosure: NEMA 1 front panel, IP20 rating
- Temperature Range: 0 to 50°C (32 to 122°F), non-condensing
- Approvals: UL, cUL, CE
Buy the Omega CN8DPT - Reliable Temperature and Process Control for Industrial Applications
Purchase the Omega CN8DPT temperature and process controller online today to experience unmatched versatility, precise measurement, and extensive control options. Its high accuracy inputs, programmable ramp/soak sequences, and multiple communication interfaces ensure seamless integration into industrial processes, manufacturing, and research applications. With a durable NEMA 1 enclosure, user-friendly display, and robust certifications, this controller offers reliable performance for demanding environments. Order now for fast delivery and enhance your process control capabilities with this versatile, easy-to-use device designed for precision and durability.
Get Omega CN8DPT today—built for precise temperature control and industrial reliability.
Frequently Asked Questions
Where can I buy OMEGA CN8DPT330?
You can click on the BUY or RFQ button to purchase CN8DPT330 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN8DPT330?
You can download the CN8DPT330 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN8DPT330?
OMEGA
