OMEGA CNI16D22C24 Industrial Process Controller
The CNi16 Series DIN temperature and process controllers provide high-accuracy measurements with 0.5°C and 0.03% reading resolution, featuring programmable digital filtering, color display options, and embedded Ethernet connectivity. Suitable for industrial automation, these fully programmable PID controllers support various input types like thermocouples, RTDs, and analog signals, with options for dual displays, control outputs, and communication protocols including RS232, RS485, and Ethernet. With NEMA 4 (IP65) front bezels and robust design, they are ideal for precise temperature and process control in demanding industrial environments.
OMEGA CNI16D22C24 Industrial Process Controller Specifications:
- Accuracy: +0.5°C temperature; 0.03% reading
- Resolution: 1°/0.1°; 10 UV process
- Temperature Stability: RTD 0.04°C/°C, Thermocouple 0.05°C/°C @ 25°C
- Input Types: Thermocouple, RTD, analog voltage, current
- Thermocouples: J, K, T, E, R, S, B, C, N, L
- RTD Input: 100/500/1000 Ω Pt sensors, 2/3/4-wire; class B or A
- Voltage Input: 0-100 mV, 0-1 V, 0-10 V
- Current Input: 0-20 mA, unipolar
- Control Mode: PID, manual, auto, on/off, proportional, derivative, integral
- Relay Output: 250 Vac or 30 Vdc @ 3 A resistive load
- Ethernet: IEEE 802.3 10Base-T, TCP/IP, HTTP, Web server
- Serial: RS232, RS485, ASCII and MODBUS protocols, 300-19.2 Kb
- Power Supply: 90-240 Vac ±10%, or 24 Vac/DC options
- Environmental: 0-55°C, 90% RH non-condensing
- Protection: NEMA 4X/IP65 front bezel, UL, CE, C-UL approvals
- Dimensions: 48 H x 96 W x 127 mm D for i/8 series, with corresponding cutouts.
Buy the Omega CNi16 Series – Reliable Industrial Temperature Control for Industrial Applications
Purchase the Omega CNi16 Series industrial process controller online today and upgrade your automation system with high accuracy, programmable filtering, and robust communication options. Featuring easy setup, color display, Ethernet connectivity, and multiple input types, this DIN-sized controller is ideal for demanding industrial environments. Enjoy fast delivery and reliable performance that helps maintain optimum process conditions, reduce downtime, and improve operational efficiency. Elevate your project with dependable control technology—order now to experience seamless integration and superior productivity.
Order your Omega CNi16 Series temperature controller today and ensure precise, reliable temperature management for your industrial projects.
Frequently Asked Questions
Where can I buy OMEGA CNI16D22C24?
You can click on the BUY or RFQ button to purchase CNI16D22C24 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CNI16D22C24?
You can download the CNI16D22C24 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CNI16D22C24?
OMEGA
