OMEGA DP25BSA Strain Gauge Meter
The digital programmable strain meter is a versatile indicator and controller designed for precise measurement of strain. It features a four-digit display with extensive scaling options, capable of showing measurements in various engineering units. The device supports multiple DC current and voltage input ranges suitable for typical strain gauge applications. It can accept strain gauge bridge or process signals, offers selectable excitation voltages compatible with most transducers and transmitters, and includes a hardware lockout to prevent unauthorized setup changes. Additional features include peak detection, sensor excitation, and remote or front panel tare functions.
OMEGA DP25BSA Strain Gauge Meter Specifications:
- Display: 4-digit, 9-segment, 21 mm (0.83'') high LED, selectable color
- Inputs: DC voltage, current, strain gages, thermocouples, RTDs
- Input Ranges: 0 to 10V, 0 to 20 mA, 4 to 20 mA, 0 to 100 mV, +50 mV
- Accuracy: ±0.5°C (0.9°F) after 30 min warm-up
- Resolution: 15-bit internal dual slope ADC
- Relay Outputs: 2 form C (SPDT), 5 A 250 Vac, programmable alarms
- Analog Output: Optional 0-10 V, 4-20 mA, 0-20 mA, scalable for retransmission or control
- Power Supply: 115 Vac or 230 Vac (+10%), 8 W max, 26-56 Vdc options
- Isolation: Dielectric strength to 2500 V, EMC compliance, EN61010 safety
- Dimensions: 48 mm H x 96 mm W x 152 mm D, panel cutout 45 mm H x 92 mm W
- Operating Temperature: 0 to 50°C (32 to 122°F), Storage: -40 to 85°C
- Other features: remote tare, peak detection, hardware lockout, multiple excitation voltages
Buy the Omega Series DP25B Strain Gauge Meter: DP25BSA
Purchase the Omega DP25BSA strain gauge meter online and enjoy a versatile, highly accurate device designed for industrial strain applications. With a bright, programmable display, multiple input ranges, and optional relays and analog outputs, this meter provides excellent signal conditioning and control capabilities. Its robust design, including built-in excitation for transducers, remote tare function, and high immunity to noise, makes it ideal for precise strain measurement and process control needs. Buy online now for reliable performance and easy setup in your automation systems.
Get Omega DP25BSA today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy OMEGA DP25BSA?
You can click on the BUY or RFQ button to purchase DP25BSA from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DP25BSA?
You can download the DP25BSA datasheet or visit the OMEGA website for support.
Who is the manufacturer of DP25BSA?
OMEGA
