OMEGA DPI16 Process Temperature & Control Meter
The DPI16 is a precision temperature and process instrument designed for accurate measurement with high stability and versatile signal input options. It supports thermocouples, RTDs, voltage, and current signals, featuring a large programmable color display, embedded Ethernet connectivity, and multiple communication protocols including RS232, RS485, and TCP/IP. Its robust construction, NEMA 4X front bezel, and comprehensive calibration and linearization capabilities make it ideal for industrial temperature and process monitoring or control applications requiring accuracy, reliability, and ease of integration.
OMEGA DPI16 Process Temperature & Control Meter Specifications:
- Accuracy: ±0.5°C temperature, 0.03% reading
- Display: 4-digit 9-segment LED with programmable color
- Input Types: Thermocouple J, K, T, E, R, S, B, C, N, L; RTD 100/500/1000 2-wire/3-wire/4-wire; Analog voltage 0-100mV, 0-1V, 0-10V; Current 0-20mA
- Temperature Stability: RTD 0.04°C/°C, Thermocouple 0.05°C/°C at 25°C
- Communication: Ethernet (TCP/IP), RS232, RS485/422, Protocols supported: TCP/IP, HTTP, MODBUS
- Power: 90-240 Vac, or 24 Vac/DC optional low-voltage power
- Dimensions: 48 H x 48 W x 127 mm D, Panel cutout: 45 mm square
- Environmental: 0-55°C, 90% RH non-condensing, NEMA 4X/IP65 compatible front bezel
- Additional features: Digital filter, linearization points up to 10, user-configurable alarms and setpoints
Buy the Buy Omega Temperature and Process Meter Part Number DPI16 Online
Discover the Omega DPI16, a high-precision process and temperature monitor with versatile inputs and advanced features. Featuring an easy-to-read programmable color display, Ethernet connectivity, and multiple communication protocols, it simplifies integration into industrial systems. Its robust construction ensures durability in harsh environments, with certifications for UL, CE, and FM compliance. Perfect for temperature control, process monitoring, and automation applications, the DPI16 provides unmatched accuracy and reliability, making it an essential component in any industrial instrumentation setup.
Buy Omega DPI16 now and experience precise temperature and process measurement for industrial control with advanced connectivity and programmable display.
Frequently Asked Questions
Where can I buy OMEGA DPI16?
You can click on the BUY or RFQ button to purchase DPI16 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DPI16?
You can download the DPI16 datasheet or visit the OMEGA website for support.
Who is the manufacturer of DPI16?
OMEGA
