OMEGA DPI8AL Temperature Process Meter
The DPi8AL is a versatile, high-accuracy temperature and process meter with alarm outputs, featuring universal inputs such as thermocouples, RTDs, analog voltage, and current. It offers programmable digital filters, built-in excitation, and a color display for visual alarms. The device supports multiple alarm conditions, is front-removable and plug-connected, and can be powered via AC or DC sources. Ideal for industrial process monitoring, it ensures reliable measurements with easy configuration and compatibility with various engineering units.
OMEGA DPI8AL Temperature Process Meter Specifications:
- Input Types: Thermocouple, RTD, analog voltage, analog current
- Accuracy: +0.5°C temperature; 0.03% rdg
- RTD Input: 100/500/1000 Q Pt sensor, 2-, 3- or 4-wire; 0.00385 or 0.00392 curve
- Thermocouple Types: J, K, T, E, R, S, B, C, N, L according to ITS 90
- Voltage Input: 0 to 100 mV, 0 to 1 V, 0 to 10 V dc
- Display: 4-digit 9-segment LED, 21 mm (0.83")
- Alarm Outputs: 2 SPDT relays, 250 Vac or 30 Vdc @ 3A (resistive load)
- Power Supply: 90-240 Vac or 12-36 Vdc low voltage option
- Operating Temperature: 0 to 55°C, 32 to 131°F
- Protection: NEMA 1 front bezel or NEMA 4X/IP65 for DIN models
- Dimensions: Varies by model, approximately 48 x 96 x 127 mm
Buy the Buy Omega Temperature Process Meter Part Number DPI8AL Online
Purchase the Omega DPI8AL process meter online to ensure precise temperature and process monitoring for industrial applications. This multivariable device supports thermocouples, RTDs, voltage, and current inputs, providing customizable alarm conditions for safety and efficiency. Featuring a large, multi-color display and front removable connectors, it simplifies setup and maintenance. The device's built-in excitation, versatile power options, and rugged NEMA protection make it ideal for demanding environments. Order now for fast delivery and trusted performance in your industrial control systems.
Buy Omega DPI8AL now and experience unmatched reliability and high-precision temperature and process measurement with programmable alarms.
Frequently Asked Questions
Where can I buy OMEGA DPI8AL?
You can click on the BUY or RFQ button to purchase DPI8AL from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DPI8AL?
You can download the DPI8AL datasheet or visit the OMEGA website for support.
Who is the manufacturer of DPI8AL?
OMEGA
