OMEGA DPM35A Process Indicator
The DPM35A is a compact, panel-mounted process indicator requiring only 70 mm of depth behind the panel. It features a 3% digit LED display, large 10 mm digits, and accepts a wide input voltage range from 0 to 200 Vdc or 0 to 20 mA. The device offers scaling for zero and span, jumper-selectable decimal point, and a rear screw-clamp connector. It operates accurately within -20 to 60°C, consumes 0.6 W at 24 Vdc, and is ideal for industrial process monitoring with minimal panel depth and reliable performance.
OMEGA DPM35A Process Indicator Specifications:
- Display: 3% digit, 0 to 1999; 7-segment LED
- Input Voltage Range: 0 to 200 Vdc or 0 to 20 mA
- Power Supply: 10 to 30 Vdc, isolated
- Power Consumption: 0.6 W at 24 Vdc
- Operating Temperature: -20 to 60°C
- Dimensions: DPM35A: 24 H x 48 W x 70 mm D (0.94 x 1.89 x 2.76 inches)
- Panel Cutout: 22.2 x 45 mm (0.87 x 1.77 inches)
- Display Size: 10 mm (0.4 inch)
- Input Configuration: Bipolar single, dual slope A/D converter
- Reading Rate: 2.5 per second
- Accuracy: 0.2% + 1 count
- Polarity: Automatic, minus sign indicator
- Temperature Coefficient: <50 ppm
- Input Impedance: High, for accurate measurement
- Jumper-Selectable Decimal Point: 1.XXX, 1X.XX, 1XX.X
Buy the Omega Series DPM35A Process Indicator: 0-200V/20mA, Compact Panel Mount
Order the Omega DPM35A process indicator online today and enjoy reliable, accurate measurement for your industrial applications. With a compact design, large 10 mm digits, and scalable inputs, it is easily installed behind panels requiring just 70 mm depth. Its versatile input options, jumper-selectable decimal point, and precise accuracy of 0.2% ensure optimal performance. Ideal for monitoring voltage or current signals, this device supports a wide temperature range from -20 to 60°C, consumes only 0.6 W, and offers straightforward operation with screw-clamp connectors for quick wiring.
Buy Omega DPM35A now and experience unmatched reliability and performance in process measurement with minimal panel depth.
