OMEGA LCR5K industrial force load cell
The Omega LCR-5K is a high-accuracy industrial S-beam load cell with a 5000 lb capacity, suitable for precise force measurement applications. Constructed from durable 17-4 PH stainless steel and rated IP55, it offers excellent performance with ±0.03% linearity, ±0.02% hysteresis, and ±0.10% repeatability. Operating within -18°C to 71°C (0°F to 150°F), it withstands overloads up to 150% of capacity and ultimate overloads to 300%. Compatible with digital meters such as DP41-S, DPiS, and DP25B-S, it features a 3mV/V ±0.25% output, making it ideal for industrial force testing and measurement tasks.
OMEGA LCR5K industrial force load cell Specifications:
- Capacity: 5000 lb (2269 kgf)
- Material: 17-4 PH stainless steel
- Protection Level: IP55
- Output: 3 mV/V ±0.25%
- Excitation: 10 VDC, maximum 15 VDC
- Linearity: ±0.03%
- Hysteresis: ±0.02%
- Repeatability: ±0.10%
- Operating Temperature Range: -18°C to 71°C (0°F to 150°F)
- Overload Capacity: 150% of capacity
- Ultimate Overload: 300% of capacity
- Compatible with DPiS, DP41-S, DP25B-S meters
Buy the Omega Series LCR Load Cell: 5000 lb Capacity
Experience reliable and high-precision force measurement with the Omega LCR-5K load cell. Designed for industrial applications, it features rugged stainless steel construction, IP55 protection, and a precise 3mV/V output. This load cell supports a capacity of 5000 lb, with excellent linearity and hysteresis for accurate testing. Compatible with popular digital meters, it withstands heavy overloads, making it ideal for force testing, material testing, and force measurement operations in manufacturing settings. Purchase online today for durability and dependable performance.
Get Omega LCR-5K today—built for precision and long-lasting durability in demanding industrial environments.
