OMEGA PX3005012ADAPTOR Differential Pressure Transmitter
The PX3005-DIFF pressure transmitter features a compact, rangeable design with a rugged IP67-rated stainless-steel enclosure, suitable for washdown environments. With a 5-digit backlit LCD, it displays process variables, and its advanced MEMs piezoresistive sensor ensures high accuracy and reliability. Capable of monitoring pressures from 1 to 1,500 psi, it offers adjustable zero and span, supporting multiple measurement units. Its versatile output and configuration options make it ideal for hydraulic systems, process automation, and tank level applications, delivering precise and durable performance under demanding conditions.
OMEGA PX3005012ADAPTOR Differential Pressure Transmitter Specifications:
- Power Supply: 10.5 to 55VDC
- Output Signal: 4 to 20mA two-wire, linear or square root output selectable
- Accuracy: +0.075% span
- Long Term Stability: +0.2% URL/60 months
- Ambient Temperature: -20 to 80°C (-4 to 176°F)
- Operating Temperature: -20 to 70°C (-4 to 160°F)
- Media Temperature: -40 to 120°C (-40 to 250°F)
- Environmental Rating: IP67
- Process Connection: %
- 316 SS F/316 SS
- Electrical Connection: 4 pin male M12
- Housing Material: 316 SS
- Weight: Approx. 3kg
- Vibration Effects: Less than 0.1% URL at 20g
- Sensor Response Time: 200ms
- Transmission Distance: Up to 1000m
- Seal Material: FKM O-ring
- Fill Fluid: Silicone Oil
Buy the Omega Series Differential Pressure Transmitter: PX3005-DIFF
Enhance your industrial process control with the Omega Differential Pressure Transmitter. Its rugged stainless-steel enclosure, versatile measurement ranges up to 1500 psi, and advanced sensor technology ensure reliable performance and precise pressure monitoring. Equipped with a backlit LCD, adjustable zero/span, and configurable output signals, it is ideal for hydraulic systems, tanks, and automation applications. Easy to install, suitable for washdown environments, and capable of operating across wide temperature ranges, this device guarantees durability and accuracy for critical industrial measurements.
Buy Omega PX3005-DIFF now and experience unmatched reliability and high-accuracy pressure measurement in demanding industrial environments.
