OMEGA PX300525WDWBI Differential Pressure Transmitter
The PX3005-DIFF pressure transmitter with display is a compact, rangeable device designed for precise pressure monitoring in process automation, hydraulics, and tank applications. Featuring a MEMs piezoresistive sensor, the rugged IP67 stainless steel enclosure ensures durability and washdown suitability. It offers a backlit LCD, configurable 4-20 mA output, and nineteen measurement units. Its high rangeability from -100% to 100% FS allows for flexible setup, while stability and accuracy make it suitable for demanding industrial environments, supporting pressures up to 1,500 psi.
OMEGA PX300525WDWBI Differential Pressure Transmitter Specifications:
- Power Supply: 10.5 to 55VDC
- Output Signal: 4 to 20mA, linear or square root output selectable
- Accuracy: ±0.075% of span
- Long Term Stability: ±0.2% URL per 60 months
- Operating Temperature: -20 to 70°C
- Media Temperature: -40 to 120°C
- Enclosure: IP67, 316 stainless steel
- Sensor Fill Fluid: Silicone Oil
- Mounting: Compatible with standard process connections, including ½-18NPT F / 316 SS
- Response Time: 200 ms
- Vibration: 20g, tested per IEC standards
- Transmission Range: Less than 1000 meters
- Weight: About 3kg without mounting accessories
Buy the Omega PX3005-U1500 – Reliable Differential Pressure Transmitter for Industrial Applications
Enhance your industrial pressure monitoring with the Omega PX3005-DIFF transmitter featuring a robust IP67 stainless steel enclosure, a bright backlit LCD, and configurable 4-20 mA output. Designed for precision and durability, it supports ranges up to 1500 psi and nineteen measurement units for versatile use in process automation, hydraulic systems, and tank levels. Easy to install and configure, this rangeable device ensures dependable operation in washdown and demanding environments, making it ideal for engineers seeking high performance and reliable pressure data.
Order your Omega PX3005-25WDWBI pressure sensor with display today and ensure accurate, reliable pressure measurement for your industrial projects.
Frequently Asked Questions
Where can I buy OMEGA PX300525WDWBI?
You can click on the BUY or RFQ button to purchase PX300525WDWBI from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX300525WDWBI?
You can download the PX300525WDWBI datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX300525WDWBI?
OMEGA
