ONSEMI 74ACT541MTCX Octal Buffer
The 74ACT541MTCX is an octal buffer and line driver with 3-state outputs, designed for use as memory and address drivers, clock drivers, and bus-oriented transmitter/receivers. It features a flow-through architecture with inputs on one side and outputs on the opposite side, facilitating easy interface with microprocessors and enabling higher PCB density. The device offers reduced supply current (ICC) and output leakage (IOZ) by 50%, with outputs capable of sourcing and sinking up to 24mA. Its TTL-compatible inputs make it suitable for industrial, clock and timing, and signal processing applications.
ONSEMI 74ACT541MTCX Octal Buffer Specifications:
- Supply Voltage: Vcc = 4.5V to 5.5V
- Input Voltage: OV to Vcc
- Output Current: ±24mA source/sink
- Output Voltage: VOH, VOL as per TTL compatibility
- Output Leakage Current: IOZ max 42.5nA at Vcc=5.5V
- Power Dissipation Capacitance: 70.0pF for ACT, 30.0pF for AC
- Propagation Delay: 2.0ns to 8.0ns depending on conditions
- Storage Temperature: -65°C to +150°C
- Operating Temperature: 40°C to +85°C
- Package Types: SOIC, SOP, TSSOP, PDIP
Buy the ON Semiconductor 74ACT541MTCX – Reliable Octal Buffer for Industrial Applications
Purchase the ON Semiconductor 74ACT541MTCX online today and enhance your electronic projects with a high-performance octal buffer. This robust device supports high-speed, reliable operation with TTL-compatible inputs and a flow-through architecture that simplifies PCB layout. Capable of sourcing and sinking 24mA, it is suitable for memory, address, clock, and bus systems in industrial and signal processing applications. Economical and easy to incorporate, order now to ensure your designs meet rigorous performance standards instantly.
Order your ON Semiconductor 74ACT541MTCX today and give your projects the dependable quality they deserve, especially for microprocessor and bus interface systems.
Frequently Asked Questions
Where can I buy ONSEMI 74ACT541MTCX?
You can click on the BUY or RFQ button to purchase 74ACT541MTCX from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part 74ACT541MTCX?
You can download the 74ACT541MTCX datasheet or visit the ONSEMI website for support.
Who is the manufacturer of 74ACT541MTCX?
ONSEMI
