ONSEMI M74VHC1GT02DTT1G Logic Level Shifter
The MC74VHC1GT02 is a high-speed, single 2-input NOR gate CMOS logic level shifter compatible with TTL input thresholds and CMOS output levels. It features overvoltage protection on inputs up to 7 V, making it suitable for interface applications between different logic levels, including 3 V and 5 V systems. The device offers low power dissipation, balanced propagation delays, and includes power-down protection. It is ideal for high-speed digital circuits requiring reliable level translation and noise immunity, with protection against voltage mismatch and hot insertion conditions.
ONSEMI M74VHC1GT02DTT1G Logic Level Shifter Specifications:
- Supply Voltage Range: 3.0 V to 5.5 V
- Input Voltage Range: 0.0 V to 7.0 V
- Maximum DC Supply Voltage: 7.0 V
- Input Voltage Threshold: TTL-compatible (0.8 V typical for LOW, 2 V for HIGH)
- Output Voltage Swing: Full 5 V CMOS levels
- Propagation Delay: 10.0 ns at Vcc=3.3 V, 11.0 ns at Vcc=5 V
- Power Dissipation: Max 200 mW at 85°C
- Input Protection: Up to 7 V overvoltage tolerance
- Input/Output Protection: Power-down, hot insertion safeguards
- Operating Temperature Range: -55°C to +125°C
- ESD Resistance: >2000 V Human Body Model
- Junction Temperature: Max +150°C
Buy the Buy ON Semiconductor MC74VHC1GT02 Part Number M74VHC1GT02D Online
Enhance your digital circuit performance by purchasing the high-speed ON Semiconductor MC74VHC1GT02 logic level shifter online. Designed for reliable voltage translation between 3 V and 5 V systems, this device offers TTL-compatible inputs, CMOS output levels, and robust overvoltage protection up to 7 V. Its low power dissipation and balanced propagation delays make it ideal for high-speed applications requiring noise immunity and hot insertion safeguards. Order now to ensure seamless, efficient, and safe logic level translation for your complex electronic projects.
Buy ON Semiconductor MC74VHC1GT02D now and experience unmatched reliability and high-speed logic level shifting for your digital interface needs.
