ONSEMI MC33067PG Resonant Mode Controller
The MC34067/MC33067 are high performance zero voltage switch resonant mode controllers designed for off-line and dc-dc converter applications. They feature a variable frequency oscillator, a precise retriggerable one-shot timer, temperature compensated reference, high gain wide bandwidth error amplifier, steering flip-flop, and dual high-current totem pole outputs for driving power MOSFETs. Built-in protections include fault comparator, input undervoltage lockout, programmable soft-start circuitry, and reset circuitry to ensure safe and efficient operation in high-frequency resonant power supply designs. These devices are available in dual-line and surface-mount packages suitable for industrial and automotive applications.
ONSEMI MC33067PG Resonant Mode Controller Specifications:
- Power Supply Voltage: 20 V
- Drive Output Current: 1.5 A
- Frequency Range: Exceeding 1.0 MHz, control range 1000:1
- Reference Voltage: 5.1 V, initial accuracy ±2%
- Thermal Resistance Junction-to-Air: 148 °C/W for plastic package
- Operating Junction Temperature: 0°C to +150°C (MC34067), -40°C to +85°C (MC33067, NCV33067)
- Storage Temperature: -55°C to +150°C
- Error Amplifier Gain: >70 dB
- Error Amplifier Bandwidth: 2.5 MHz
- Output Saturation Voltage: 0.6 V (low), 20 V (high)
- UVLO Thresholds: 3.8 V to 4.3 V (with adjustable thresholds)
- Pulse Timing: One-Shot period approximately 250 ns ±5%
- Package Types: SOIC-16W, PDIP-16
- ESD Capability: 2.0 kV HBM, 1.0 kV CDM
- RoHS, Halogen, BFR free, Pb-Free compliance
Buy the ON Semiconductor MC33067PG – Reliable Resonant Mode Controller for Industrial Applications
Enhance your power conversion designs with the MC33067PG resonant mode controller, offering high frequency operation exceeding 1 MHz, built-in fault protections, and a precision 5.1 V voltage reference. Its high current totem pole outputs, adjustable undervoltage lockout, and versatile packaging make it ideal for industrial, automotive, and high-efficiency power supply applications. Optimize your design performance with this advanced controller, ensuring safety, efficiency, and reliable operation in demanding environments. Purchase online today to streamline your project development and ensure dependable power management.
Order your ON Semiconductor SeriesMC33067PG high-performance resonant mode controller today and give your power supply projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy ONSEMI MC33067PG?
You can click on the BUY or RFQ button to purchase MC33067PG from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MC33067PG?
You can download the MC33067PG datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MC33067PG?
ONSEMI
